System Menu
Command
Description Comment
nview Get information about
N-View
TM function.
aging Set and get info on Aging Time for
dynamically learned addresses
info
or
info1, info2,... Displays the current system status. (info for
508/9)(info1,2 for 516/7)
(info1,2,3,4 for 524)
(info1,2,3,4 for 526) LINK Status. Rate, Flow, etc.
upwd Set a user defined password.
restore Restores the defaults of the switch (complete
reset). **Note: Power cycle is required
when completed. restores the factory settings of the switch. With the
exception of the “protected settings” (see
‘Restoring Defaults’), the settings made by the user
are reset to the default values.
N-View
TM
Menu
With the N-View
TM
OPC software and an appropriate OPC viewer, one can monitor port and switch status
via the LAN. When enabled, periodic Multicast MAC packets are sent out from every port.
Note: The configuration console is only available with –A models.
Command Description Comment
info Displays the current values of the
switch settings MAC address,
Enabled or disabled
disable (or enable) Enable Disable N-View TM Choice is opposite of current state
Notes on N-View
TM
:
• With ‘-A’ option, either all ports are ‘on’, or all ports are ‘off’.
• With the ‘-N’ option all ports are ‘on’.
• Rate for generation of MIB information frames is ~6.4 seconds.
• The N-View TM
frames are not mirrored.
• The FX Port is mapped to port 9 on the 509, and as port 17 on the 517. On the 508FX2, ports 7 and 8 are FX ports. On
the 526FX, Ports 25 and 26 are FX ports.
Example of the N-View info screen:
CLI\SYSTEM\N-VIEW>info
N-View is ENABLED.
MAC ADDRESS:00-07-AF-00-05-26
/ (Go to top of menu tree)
? (Show menus/commands)
info (Get information about N-View)
disable (Disable N-View)
CLI\SYSTEM\N-VIEW>
