(Revised 8/4/2009) 20
CLI Menus and Commands
These commands are available at all menus (on a –A unit):
Command Description Comment
/ Returns you to the top of menu tree
(available in every menu) Home function
? Displays the current menu again (available
in every menu) Refresh function
Also: “u” or “U” = up one level in the menu tree
\ = home
Home Menu
You can display all the other menus from the start menu. This is displayed immediately after you login and
includes the following commands:
Command
Description Comment
info Displays information about the switch Model Number, firmware version, MAC address, which functions
are presently enabled.
SYSTEM Opens the SYSTEM menu. The SYSTEM menu is used to set the system parameters.
SWITCH Opens the SWITCH menu. You can make settings for the switch in this menu.
Top Level Info
Top level info includes Model Number, Firmware version, MAC Address, and whether or not each major
function is enabled.
Example of the (top level) info screen:
CLI>info
Self Test & System Initialization Complete..... OK!
N-TRON Industrial Ethernet Switch - Model Number: 524 TX-A.
N-Tron firmware version : 8.01
Copyright (c) 2005 N-TRON
MAC ADDRESS:00-07-AF-00-05-24
N-View is ENABLED.
Trunking (Link Aggregation) is DISABLED.
Mirroring is DISABLED.
Tagged QOS is DISABLED.
Port QOS is DISABLED.
VLAN is DISABLED.
IGMP Snooping is ENABLED.
Aging is ENABLED.
CLI>
