(Revised 8/4/2009) 15
HyperTerminal
The following configuration should be used in HyperTerminal:
Port Settings:
9600
Data Bits: 8
Parity: None
Stop bits: 1
Flow Control: None
Troubleshooting
1. Make sure the (Power LED) is ON.
2. Make sure you are supplying sufficient current for the version chosen.
3. Verify that Link LED’s are ON for connected ports.
4. Verify cabling used between stations.
5. Verify that cabling is Category 5E or greater for 100Mbit Operation.
6. For FX/FXE models, verify TX is connected to far end RX and vise versa. Also insure the
connecting partner is 100Mb/s IEEE 100BaseFX compliant. Note: the 500 Series FX/FXE
switches do not support the 10BaseFL standard.
SUPPORT
Contact N-TRON Corp. at:
TEL: 251-342-2164
FAX: 251-342-6353
www.n-tron.com
[email protected]
FCC Statement
This product complies with Part 15 of the FCC-A Rules.
Operation is subject to the following conditions:
(1) This device may not cause harmful Interference
(2) This device must accept any interference received, including interference that may cause
undesired operation.
