(Revised 8/4/2009) 30
Example of the Tagged QOS config screen:
CLI\SWITCH\QOS>set_tag
Configure Tagged QOS Threshold.
The Tagged QOS threshold is now: 4
When an incoming 802.1p priority tag value is greater than or
equal to this number, the incoming packet will be classified as
high priority.
Please Select Tagged QOS Threshold [0-7]: 6
The Tagged QOS threshold is now: 6
CLI\SWITCH\QOS>
Example of the Port QOS config screen:
CLI\SWITCH\QOS>set_port
Configure Port QOS. Select higher priority ports.
These ports are higher priority for Port QOS: none
Enter ports to enable>
Use commas to separate port numbers.
(Example: '3,6,12,14'.)
Enter Port Numbers (or ESC to exit)> 1,5,8
These ports are higher priority for Port QOS: 1 5 8
CLI\SWITCH\QOS>
Example of the QOS info screen:
CLI\SWITCH\QOS>info
Tagged (802.1P) QOS is ENABLED.
The Tagged QOS threshold is: 6.
Port QOS is ENABLED.
These ports are higher priority for Port QOS: 1 5 8
CLI\SWITCH\QOS>
