B&B Electronics, Inc. SPECTRE User Manual
45
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
6.3 Technical Parameters
SPECTRE Router
Complies with standards EN 301 511, v9.0.2,
EN 301 908-1&2, v3.2.1,
ETSI EN 301 489-1 V1.8.1,
EN 60950-1:06 ed.2 + A11:09 + A1:10
Temperature range Function
Storage -30
o
C to +60
o
C
-40 o C to +85 o C
Protection Freely
In switch board IP20
IP56
Supply voltage 10 to 30 V DC
Consumption Receive Mode
Transmit: GPRS*
Transmit: UMTS
/HSDPA/EVDO* 300 mW
to 3.5 W (GPRS transmission)
to 5.5 W (UMTS/HSDPA transmission)
Dimensions 42x76x113 mm (DIN 35mm)
Weight SPECTRE 3G – 280 g
Antenna connector* SMA – 50 Ohm
User interface ETH
USB
PORT 1
PORT 2 Ethernet (10/100 Mbit/s)
USB 2.0 type A host
Model Dependent
Model Dependent
*Wireless parameters refer to 3G models only
Table 19: Specifications
Cellular module
HSPA+ parameters bit rate 21.1 Mbps/5,76 Mbps
3GPP rel. 7 standard
UE CAT. 1 to 6, 8, 10, 12, 14
Data compress 3GPP
UMTS parameters PS bitrate – 384/384 kbps
CS bitrate – 64/64 kbps
W-CDMA FDD standard
GPRS parameters bit rate 236 kbps/236kbps
GPRS multislot class 10, CS 1 to 4
EGPRS multislot class 10, CS 1 to 4,
MCS 1 to 9
Transmit power UMTS/HSUPA/HSDPA/HSPA+ - (20dBm)
EGSM900/GSM850 - Class 4 (33dBm)
GSM1800/1900 - Class 1 (30dBm)
Support channel GSM/GPRS/EDGE
850Mhz, 900Mhz, 1800Mhz, 1900Mhz
UMTS/HSDPA/HSUPA/HSPA+
800Mhz, 850Mhz, 900Mhz,1900Mhz, 2100Mhz
Table 20: Cellular Module Specifications
