B&B Electronics, Inc. SPECTRE User Manual
10
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
2.4 Model Numbers
Standard Features on Spectre Routers: 10/100 Ethernet, USB Host Port, Binary I/O Port, Dual SIM
Card slots
Auxiliary Port Functions (Model Dependent):
The router can be connected as follows.
PORT 1 RS232, RS485/422, ETHERNET, CNT, XC-SW (in combination with PORT 2)
PORT 2 RS232, RS485/422, XC-SW (together with PORT 1)
Table 1: Auxiliary port possibilities
Spectre 3G Wireless Routers
Auxiliary Ports
Model No. Port 1 Port 2
RT3G-300 No connect No connect
RT3G-302 No connect RS-232
RT3G-310 Ethernet No connect
RT3G-311 Ethernet Ethernet
RT3G-322 RS-232 RS-232
RT3G-324 RS-232 RS-422/485
RT3G-330 12-bit I/O (AI, DI, DO) No connect
Spectre RT Wired Routers
Auxiliary Ports
Model No. Port 1 Port 2
ERT311 Ethernet Ethernet
ERT312 Ethernet RS-232
Table 2: Model numbers
Note: On routers with 2 auxiliary Ethernet ports (RT3G-311, ERT311), Ports 1 and 2 are
internally bridged together.
