4.2.1 Auxiliary Port Status Indicators

4.2.1.1 Ethernet Ports

LED port indicator

Green LED

On ...................... selected 100 Mbit/s
Off ...................... selected 10 Mbit/s

Yellow LED

On........................ the network cable is connected
Blinking ……….... data transmission
Off ....................... the network cable is not connected

Table 5: Ethernet LED status indication

4.2.1.2 RS-232 Ports

LED port indicator

Green LED

Blinks on Receive data

Yellow LED

Blinks on Transmit data

Table 6: RS-232 LED status indication

4.2.1.3 I/O Ports

LED port indicator

Green LED

Indicates binary input 0

Yellow LED

Indicates binary input 1

Table 7: I/O Port LED status indication

4.2.1.4 RS-485/422 Ports

LED port indicator

Green LED

Blinks on Receive data

Yellow LED

Blinks on Transmit data

Table 8: RS-485/422 LED status indication
