0x100F R/- 1. log – lower 16 bits of counter CNT2 value
0x1010 R/- 1. log – prompt frequency CNT2
0x1011 R/- 1. log – average frequency CNT2
0x1012 R/- 1. log – minimal frequency CNT2
0x1013 R/- 1. log – maximal frequency CNT2
0x1100 R/- 2. log
0x1200 R/- 3. log
... R/- ...
0xEF00 R/- 224. log
0xF000 -/W Samples stores period [min]
0xF001 -/W Allowed:
b it 0 – active level on input BIN1
bit 1 – active level on input BIN2
bit 2 – active level on input BIN3
bit 3 – active level on input BIN4
bit 4 – analog input AN1 lower limit overrun
bit 5 – analog input AN1 upper limit overrun
bit 6 – analog input AN2 lower limit overrun
bit 7 – analog input AN2 upper limit overrun
bit 8 – limit frequency CNT1 overrun
bit 9 – limit frequency CNT2 overrun
0xF100 -/W Binary inputs negative logical
bit 0 – input BIN1
bit 1 – input BIN2
bit 2 – input BIN3
bit 3 – input BIN4
0xF200 -/W Binary outputs normal level
bit 0 – output OUT1
0xF201 -/W Feeder – impulse number on input BIN1/CNT1
0xF202 -/W Feeder – impulse length on output OUT1 [1/8 sec]
0xF300 -/W AN1 – samples period [sec]
0xF301 -/W AN1 – multiplicative constant (with sign)
0xF302 -/W AN1 – additive constant (with sign)
0xF303 -/W AN1 – hysteresis value (with sign)
0xF304 -/W AN1 – lower limit (with sign)
