0xF305 -/W AN1 – upper limit (with sign)
0xF306 -/W bits 7-3:
AN1 – metering circuit switch time
0 → 1/64 sec
1 → 2/64 sec
...
30 → 31/64 sec
bits 2-0:
AN1 – samples number for average
0 → 1 sample
1 → 2 samples
2 → 4 samples
4 → 8 samples
5 → 16 samples
0xF400 -/W AN2 – samples period [sec]
0xF401 -/W AN2 – multiplicative constant (with sign)
0xF402 -/W AN2 – additive constant (with sign)
0xF403 -/W AN2 – hysteresis value (with sign)
0xF404 -/W AN2 – lower limit (with sign)
0xF405 -/W AN2 – upper limit (with sign)
0xF406 -/W bits 7-3:
AN2 – metering circuit switch time
0 → 1/64 sec
1 → 2/64 sec
...
30 → 31/64 sec
bits 2-0:
AN2 – samples number for average
0 → 1 sample
1 → 2 samples
2 → 4 samples
4 → 8 samples
5 → 16 samples
0xF500 -/W CNT1 – multiplicative constant
0xF501 -/W CNT1 – upper limit
0xF502 -/W CNT1 – time of limit overrun [sec]
0xF503 -/W CNT1 – time for metering reset [sec]
