bit 5 – analog input upper limit overrun AN1
bit 6 – analog input lower limit overrun AN2
bit 7 – analog input upper limit overrun AN2
bit 8 – limit frequency overrun CNT1
bit 9 – limit frequency overrun CNT2
0x0F05 R/- Binary inputs status
bit 0 – level on input BIN1
bit 1 – level on input BIN2
bit 2 – level on input BIN3
bit 3 – level on input BIN4
bit 6 – level on output BOUT1
0x0F06 R/- Recalculate AN1 value (with sign)
0x0F07 R/- Recalculate AN2 value (with sign)
0x0F08 R/- Upper 16 bits CNT1
0x0F09 R/- Lower 16 bits CNT1
0x0F0A R/- Prompt frequency CNT1
0x0F0B R/- Average frequency CNT1
0x0F0C R/- Minimal frequency CNT1
0x0F0D R/- Maximal frequency CNT1
0x0F0E R/- Upper 16 bits of counter CNT2 value
0x0F0F R/- Lower 16 bits of counter CNT2 value
0x0F10 R/- Prompt frequency CNT2
0x0F11 R/- Average frequency CNT2
0x0F12 R/- Minimal frequency CNT2
0x0F13 R/- Maximal frequency CNT2
0x1000 R/- 1. log – upper 16 bits of log number
0x1001 R/- 1. log – lower 16 bits of log number
0x1002 R/- 1. log – upper 16 bits of time stamps
0x1003 R/- 1. log – lower 16 bits of time stamps
0x1004 R/- 1. log – alarms status
0x1005 R/- 1. log – binary inputs status
0x1006 R/- 1. log – recalculate value AN1 (with sign)
0x1007 R/- 1. log – recalculate value AN2 (with sign)
0x1008 R/- 1. log – upper 16 bits CNT1
0x1009 R/- 1. log – lower 16 bits CNT1
0x100A R/- 1. log – prompt frequency CNT1
0x100B R/- 1. log – average frequency CNT1
0x100C R/- 1. log – minimal frequency CNT1
0x100D R/- 1. log – maximal frequency CNT1
0x100E R/- 1. log – upper 16 bits of counter CNT2 value
