B&B Electronics RT3G-300_310_320_330_340-W - User Manual User Manual
Page 25
B&B Electronics, Inc.
SPECTRE User Manual
25
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
Fig. 20: Jumper Position for external supply
Fig. 21: Jumper Position for RS-485
Fig. 22: Jumper Position for internal supply
Fig. 23: Jumper Position for RS-422
Jumper J2
Jumper J3
Jumper J2
Jumper J3
Jumpery J4 and J5
Jumper J6
Jumper J6
