MAX3795
1Gbps to 4.25Gbps Multirate VCSEL Driver
with Diagnostic Monitors
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________ 15
© 2004 Maxim Integrated Products Printed USA is a registered trademark of Maxim Integrated Products.
Typical Application Circuit
V
CC
REF
COMP
MD
BIAS
OUT+
OUT-
MODSET
BIASSET
R BIASSET
PWRMON
TC1
TC2
IN+
IN-
TX_DISABLE
FAULT
SQUELCH
GND
0.047 µF
+3.3V
0.1 µF
0.1 µF
R TC
†
† OPTIONAL COMPONENT
*FERRITE BEAD
PEAKSET
R PEAKSET
†
0.01 µF
0.01 µF
50 Ω
L1*
C F
†
R F
†
0.01 µF
0.01 µF
56 Ω
L1*
L2*
C F
†
R F
†
BIASMON
R BIASMON
4.7k Ω †
R PWRSET
R MODSET
MAX3795
SINGLE-ENDED DRIVE DIFFERENTIAL DRIVE
