PART PACKAGE TYPE PACKAGE CODE
MAX3795ETG
24 Thin QFN
(4mm x 4mm x 0.8mm)
T2444-1
MAX3795ETG+
24 Thin QFN
(4mm x 4mm x 0.8mm)
T2444-1
Chip Information
TRANSISTOR COUNT: 3806
PROCESS: SiGe BIPOLAR
Package Information
For the latest package outline information, go to
www.maxim-ic.com/packages.
MAX3795
1Gbps to 4.25Gbps Multirate VCSEL Driver
with Diagnostic Monitors
14 ______________________________________________________________________________________
Functional Diagram
SAFETY
CIRCUITRY
TX_DISABLE
FAULT
V CC
IN+
IN-
OUT-
OUT+
MODULATION CURRENT
GENERATOR
BIAS
GENERATOR
WITH APC
ENABLE
ENABLE
100 Ω
LASER
MODULATOR
PEAKING
CONTROL
COMP MD REF PWRMON
BIAS
BIASSET
BIASMON
PEAKSET TC1 TC2 MODSET
SQUELCH
SIGNAL
DETECT
MAX3795
R OUT R OUT
