MAX1464
Low-Power, Low-Noise Multichannel
Sensor Signal Processor
______________________________________________________________________________________
39
PS[3:1]
PS[0]
PRESCALER N
000
0
1
001
0
2
010
0
4
011
0
8
100
0
16
101
0
32
110
0
64
111
0
128
000
1
3
001
1
6
010
1
12
011
1
24
100
1
48
101
1
96
110
1
192
111
1
384
Table 32. Timer Prescaler Settings
(PS[3:0])
BITS
NAME
DESCRIPTION
15–9
—
Unused.
8
PWRA2D
Power for ADC: 1 = power enabled, 0 = disabled.
7–6
—
Unused.
5
PWRDAC2
Power for DAC2 in DOP2: 1 = power enabled, 0 = disabled.
4
PWRDAC1
Power for DAC1 in DOP1: 1 = power enabled, 0 = disabled.
3–2
—
Unused.
1
PWROP2
Power for both large and small op amps in DOP2: 1 = power enabled, 0 = disabled, op-amp
outputs are high impedance.*
0
PWROP1
Power for both LG and SM op amps in DOP1: 1 = power enabled, 0 = disabled, op-amp outputs
are high impedance.*
Table 33. Power-On Control (Address = 31h)
*Whenever the DACs are enabled, the large and/or small op amps are automatically powered up and configured as buffers, regard-
less of the state of the PWROPn and BUFn bits.
