MAX1464
Low-Power, Low-Noise Multichannel
Sensor Signal Processor
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DDF
= V
DD
= 4.5V to 5.5V, V
SSF
= V
SS
= 0V, f
CLK
= 4.0MHz, T
A
= T
MIN
to T
MAX
. Typical values are at V
DDF
= V
DD
= 5.0V, V
SSF
= V
SS
= 0V,
T
A
= +25°C, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to V
SS
.............................................................-0.3V to +6.0V
V
DDF
to V
SS
...........................................................-0.3V to +6.0V
V
SSF
to V
SS
............................................................-0.3V to +0.3V
All Other Pins to V
SS
...................................-0.3V to (V
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
28-Pin SSOP (derate 9.1mW/°C above +70°C) ..........727mW
Operating Temperature Ranges
MAX1464CAI .....................................................0°C to +70°C
MAX1464C/W.....................................................0°C to +70°C
MAX1464EAI...................................................-40°C to +85°C
MAX1464AAI ................................................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) ................................ +300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
SUPPLY
Supply Voltage
V
DD
V
SS
= V
SSF
= 0V
4.5
5.0
5.5
V
FLASH Supply Voltage
V
DDF
V
SS
= V
SSF
= 0V
4.5
5.0
5.5
V
Base Operating Current
I
BO
CPU stopped (Note 2)
575
720
890
µA
CPU Current
I
CPU
All modules off, CPU = on, additive to I
BO
,
I
CPU
= I
DD
+ I
DDF
(Note 3)
540
840
1240
µA
All modules off, ADC = on, ADC clk =
1MHz, additive to I
BO
; the CPU and ADC
are not on at the same time
690
1040
1394
ADC Current (Note 3)
I
ADC
All modules off, ADC = on, ADC clk = 7kHz,
additive to I
BO
; the CPU and ADC are not
on at the same time
465
765
1060
µA
DAC Current
I
DACn
All modules off, DAC = on, additive to I
BO
(n = 1 or 2) (Note 4)
425
550
730
µA
Large Op-Amp Current
I
OPLGn
All modules off, CPU stopped, large op
amp = on (n = 1 or 2)
430
673
1020
µA
Small Op-Amp Current
I
OPSMn
All modules off, CPU stopped, small op
amp = on (n = 1 or 2)
110
190
265
µA
POWER-ON RESET
V
DDF
POR Threshold
V
DD
> V
DDF
3.6
4.0
4.3
V
V
DDF
POR Hysteresis
-0.85
V
ANALOG INPUT
PGA[4:0] = 00000, CLK[2:0] = 000
430
PGA[4:0] = 01010
,
CLK[2:0] = 000
55
PGA[4:0] = 11111, CLK[2:0] = 000
36
k
Ω
PGA[4:0] = 00000, CLK[2:0] = 011
3.4
M
Ω
PGA[4:0] = 01010, CLK[2:0] = 011
440
PGA[4:0] = 11111, CLK[2:0] = 011
288
k
Ω
PGA[4:0] = 00000, CLK[2:0] = 110
27
PGA[4:0] = 01010, CLK[2:0] = 110
3.5
Differential Input Impedance
(INP1 to INM1 and
INP2 to INM2)
R
DIN
PGA[4:0] = 11111, CLK[2:0] = 110
2.3
M
Ω
