Description:
Perform a 16-bit shift-left operation on the contents of
X-register. The most significant bit, bit 15, is truncated
and lost. If register X is any CPU register other than
register R6, then a zero is appended into the LSB, bit 0.
If X is CPU register R6, then the data appended into the
LSB bit 0 is copied from the MSB of register R4. The
contents of register R4 are not affected. The operation
does not preserve the two’s-complement sign bit-15.
The operation is equivalent to an arithmetic multiplica-
tion by 2 on an unsigned integer value stored in regis-
ter X. The result is stored back into the X-register. The
previous contents of the X-register are overwritten
and lost.
Register X can be any of the 16 CPU registers.
PC is incremented once to point to the next instruction
in program memory.
Two’s-complement data format is not preserved.
No branching occurs.
No other registers are affected.
SRX Shift Right Register X
Op-code: 0111 XXXX BINARY 7Xh
PC-register
← PC + 1 (point to next instruction)
CPU Cycles required:
1 cycle
Description:
Perform a 15-bit shift-right operation on the contents of
X-register, preserving the contents of the two’s-comple-
ment sign bit-15 and propagating the sign bit, bit-15,
into bit-14. The least significant bit, bit 0, is truncated
and lost. The operation is equivalent to an arithmetic
division by 2. The result is stored back into the X-regis-
ter. The previous contents of the X-register are overwrit-
ten and lost.
Register X can be any of the 16 CPU registers.
PC is incremented once to point to the next instruction
in program memory.
Two’s-complement data format is preserved.
No branching occurs.
No other registers are affected.
INX Increment Register X
Op-code: 1000 XXXX BINARY 8Xh
Operation:
X-register
← X-register + 1
PC-register ← PC + 1 (point to next instruction)
CPU Cycles required:
1 cycle
Description:
Perform a 16-bit increment operation on the contents of
the X-register. Should the increment result in an over-
flow, the overflow bit is truncated and lost. The result is
stored back into the X-register. The previous contents
of the X-register are overwritten and lost.
Register X can be any of the 16 CPU registers.
PC is incremented once to point to the next instruction
in program memory.
Two’s-complement data format is preserved.
No branching occurs.
No other registers are affected.
DEX Decrement Register X
Op-code: 1001 XXXX BINARY 9Xh
Operation:
X-register
← X-register - 1
PC-register ← PC + 1 (point to next instruction)
CPU Cycles required:
1 cycle
Description:
Perform a 16-bit decrement operation on the contents
of the X-register. Should the decrement result in an
underflow, the underflow bit is truncated and lost. The
result is stored back into the X-register. The previous
contents of the X-register are overwritten and lost.
Register X can be any of the 16 CPU registers.
PC is incremented once to point to the next instruction
in program memory.
Two’s-complement data format is preserved.
No branching occurs.
No other registers are affected.
NGX Negate Register X
Op-code: 1010 XXXX BINARY AXh
Operation:
X-register
← NOT X-register
14 15 13 12 11 10 9 8 7 6 5 4 3 2 1 0 BIT:
REGISTER X
Operation
