BO8032A
Feature
Mechanical Data
Item
Module Dimension
Viewing Area
Dot Size
Dot Pitch
Standard Value Unit
Pin Assignment
Input Voltage
Supply Current
LCD Driving
Voltage Vdd
Idd
Vdd-Vo
Vdd = +3V
Vdd = +3V
25 C
3.0
0.5
5.6
V
mA
V
Typical
Value
Electronic Characteristics
mm
mm
mm
mm 44.0 x 30.0
40.0 x 17.2
0.45 x 0.45
0.48 x 0.48
Dimension
BO LYMIN
1. COG package
2. Built-in controller KS0713(S6B1713)
3. +3V power supply
4. 1/32 duty cycle
5. +2.4V~+3.6V single power supply
6. Option: EL Backlight
7. Serial interface
o
Item Symbol Condition
Unit
Pin Symbol Function
1
2
3
4
5
6
7
8
9
GND
Power supply for logic
Reset signal
Data/Command
H:Data read , L:Data write
Enable signal
Serial data input
Serial clock
Chip select
Vss
Vdd
/RESET
RS
R/W
E
SID
SCLK
/CS
10 NC
