Standard ICs
Single OR gate
BU4S71
The BU4S71 is an ultra-compact IC with one circuit of the dual-input positive logic OR gate built into an SMP pack-
age.
•
Features
1) Low current dissipation.
2) Super-mini mold package designed for surface
mounting.
3) Wide range of operating power supply voltage.
4) Direct drive of 2 L-TTL inputs and 1 LS-TTL input.
•
Block diagram
•
Recommended operating conditions (Ta = 25°C, V
SS
= 0V)
5 4
1 2 3
V DD Y
A B V SS
Parameter Symbol Min. Typ. Max. Unit
V
DD
3 — 16 V
V
IN
0 — V
DD
V
Power supply voltage
Input voltage
•
Absolute maximum ratings (Ta = 25°C)
Parameter Symbol Limits Unit
V
DD
V
SS
– 0.3 ~ V
SS
+ 18 V
170 mW
I
IN
mA
Topr
V
IN
V
Tstg
Pd
Power supply voltage
Power dissipation
Input current
Operating temperature
Storage temperature
Input voltage
Note 1: These values indicate the range limits of the voltage that can be applied to each pin without
destroying it. Operation is not guaranteed at these values.
Note 2: Reduced by 1.7mW for each increase in Ta of 1
°
C over 25
°
C.
±
10
V
SS
– 0.3 ~ V
DD
+ 0.3
°
C
°
C
– 40 ~ + 85
– 55 ~ + 150
