14. Electrical Specifications
14.1 Absolute Maximum Ratings*
14.2 DC and AC Operating Range
14.3 DC Characteristics
Temperature under Bias........................-55°C to +125°C *NOTICE: Stresses beyond those listed under “Abso-
lute Maximum Ratings” may cause perma-
nent damage to the device. This is a stress
rating only and functional operation of the
device at these or any other conditions
beyond those indicated in the operational
sections of this specification is not implied.
Exposure to absolute maximum rating con-
ditions for extended periods may affect
device reliability.
Storage Temperature ............................-65°C to +150°C
All Input Voltages
(including NC Pins)
with Respect to Ground............................-0.6V to +4.1V
All Output Voltages
with Respect to Ground....................-0.6V to V
CC
+ 0.5V
AT25DF081A
Operating Temperature (Case) Ind. -40°C to 85°C
V
CC
Power Supply 2.7V to 3.6V
Symbol Parameter Condition Min Typ Max Units
I
SB
Standby Current
CS, WP, HOLD = V
CC
,
all inputs at CMOS levels
25 50 µA
I
DPD
Deep Power-down Current
CS, WP, HOLD = V
CC
,
all inputs at CMOS levels
5 10 µA
I
CC1
Active Current, Read Operation
f = 100MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
17 20
mA
f = 85MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
16 19
f = 66MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
15 18
f = 50MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
14 17
f = 33MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
13 16
f = 20MHz; I
OUT
= 0mA;
CS = V
IL
, V
CC
= Max
12 15
I
CC2
Active Current, Program Operation CS = V
CC
, V
CC
= Max 10 15 mA
I
CC3
Active Current, Erase Operation CS = V
CC
, V
CC
= Max 12 18 mA
I
LI
Input Leakage Current V
IN
= CMOS levels 1 µA
I
LO
Output Leakage Current V
OUT
= CMOS levels 1 µA
V
IL
Input Low Voltage 0.3 x V
CC
V
V
IH
Input High Voltage 0.7 x V
CC
V
V
OL
Output Low Voltage I
OL
= 1.6mA; V
CC
= Min 0.4 V
V
OH
Output High Voltage I
OH
= -100µA; V
CC
= Min V
CC
- 0.2V V
