104
AT90S8515
0841G–09/01
Figure 86. I/O Pin Input Hysteresis vs. V
CC
Figure 87. I/O Pin Sink Current vs. Output Voltage
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
0.16
0.18
2.7 4.0 5.0
Input hysteresis (V)
V
cc
I/O PIN INPUT HYSTERESIS vs. V
cc
T = 25 ˚ C
A
0
5
10
15
20
25
0 0.5 1 1.5 2
I
(mA)
OL
V (V)
OL
T = 85 ˚ C
A
T = 25 ˚ C
A
I/O PIN SINK CURRENT vs. OUTPUT VOLTAGE
V = 2.7V
cc
