Power-Management ICs for
ICERA E400/E450 Platform
MAX8982A/MAX8982X
65
Table 53. BUCK4 Register (Output Voltage Setting for BUCK4)
Note: This register is not used by the MAX8982X.
ADDRESS
(HEX)
POR
(HEX)
R/W BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
73 08 R/W Reserved Reserved Reserved Reserved SD4[3:0]
BITS 7:4 Reserved, write 0000 to these bits.
DESCRIPTION
BIT 3 BIT 2 BIT 1 BIT 0 V PROG (V)
0 0 0 0 3.00
0 0 0 1 3.05
0 0 1 0 3.10
0 0 1 1 3.15
0 1 0 0 3.20
0 1 0 1 3.25
0 1 1 0 3.30
0 1 1 1 3.35
1 0 0 0 3.40
1 0 0 1 3.45
1 0 1 0 3.50
1 0 1 1 3.55
1 1 0 0 3.60
1 1 0 1 3.65
1 1 1 0 3.70
1 1 1 1 3.75
