Power-Management ICs for
ICERA E400/E450 Platform
MAX8982A/MAX8982X
49
Table 17. LED2FT2 Register (LED2 (DR2) Flash Timer t
1
Setting)
Table 18. LED2FT3 Register (LED2 (DR2) Flash Timer t
2
Setting)
Table 19. LED2FT4 Register (LED2 (DR2) Flash Timer t
3
Setting)
ADDRESS
(HEX)
POR
(HEX)
R/W BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
21 00 R/W Reserved LD2T1[6:0]
NAME POR DESCRIPTION
LD2T1[6:0] 0000000
BIT t 1 TIME
(ms) 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 1 25
.
. .
. .
. .
. .
. .
. .
. .
.
1 1 1 1 1 1 1 3175
From 0ms to 3175ms in 25ms increments.
ADDRESS
(HEX)
POR
(HEX)
R/W BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
22 00 R/W Reserved LD2T2[6:0]
NAME POR DESCRIPTION
LD2T2[6:0] 0000000
BIT t 2 TIME
(ms) 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 1 25
.
. .
. .
. .
. .
. .
. .
. .
.
1 1 1 1 1 1 1 3175
From 0ms to 3175ms in 25ms increments.
ADDRESS
(HEX)
POR
(HEX)
R/W BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
23 00 R/W Reserved LD2T3[6:0]
NAME POR DESCRIPTION
LD2T3[6:0] 0000000
BIT t
3
TIME
(ms) 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 1 25
0 0 0 0 0 1 0 50
.
. .
. .
. .
. .
. .
. .
. .
.
1 1 1 1 1 1 1 3175
From 0ms to 3175ms in 25ms increments.
