Operating instructions, 9061 function submenu list and descriptions – Cobalt Digital COMPASS 9061 Up_Down_Cross Converter User Manual
Page 85
9061-OM (V4.9)
9061 PRODUCT MANUAL
3-41
Operating Instructions
9061 Function Submenu List and Descriptions
(continued)
• Mute Control
Allows pushbutton On/Off channel muting while saving all other settings.
• Phase Control
Selects between Normal and Invert phase (relative to source original
phase) for the destination AES output channel.
Table 3-2
9061 Function Submenu List — continued
