Introduction
Technical Specifications
Technical Specifications
Table 1-3 lists the technical specifications for the 9061 card.
Table 1-3 Technical Specifications
Item Characteristic
Part number, nomenclature 9061 Up/Down/Cross Converter with Analog/SDI Input, Audio
Embed/De-Embed, Frame Sync, Timecode, and Closed Caption
Support
Installation/usage environment Intended for installation and usage in frame meeting openGear™
modular system definition.
Power consumption < 24 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Indicators Card edge display and indicators as follows:
• 4-character alphanumeric display
• Status/Error LED indicator
• Input Format LED indicator
Controls Card edge switches as follows:
• Menu Enter pushbutton switch
• Menu Exit pushbutton switch
• Up/down selection toggle switch
Internal Tone Generators Four built-in tone generators, each configurable for 18 discrete
sine wave frequencies ranging from 50 Hz to 16 kHz.
Generator source signal level is equivalent to -20 dBu.
A/D Process HD: 4:4:4
SD: 8:8:8
Resolution: 12-bit A/D and 10-bit video data path
SD Comb Filter: 5-line adaptive
Serial Digital Video Input Data Rates Supported:
SMPTE 292 HD-SDI: 1.485 Gbps or 1.485/1.001 Gbps
SMPTE 259M-C SD-SDI: 270 Mbps
Impedance:
75 Ω terminating
Equalization (HD):
328 ft (100 m) Belden 1694A
