3
9061 Function Submenu List and Descriptions
3-24 9061 PRODUCT MANUAL 9061-OM (V4.9)
(continued)
• Safe Action/Title Area Color Selects the Safe Action and Safe Title overlay color from choices shown
to the left.
• 0.75H Safe Action Area When enabled (On), turns on the 0.75H Safe Action Area overlay that
shows the 4:3 safe area on a 16:9 image (i.e., the resulting safe area
when the image is converted to 4:3).
Note: If 0.75H (Pillar Box) is selected using the Aspect Ratio Conversion
tool in the Scaler function, and Overlays Follow ARC is selected
for this function, the overlays will be additionally reduced 0.75H
beyond the standard 4:3 safe areas.
Table 3-2 9061 Function Submenu List — continued
Outline shows 0.75H Safe Action Area boundary. Color of boundary
is selected using Color drop-down list.
