9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells) 77
Reduction Wheel Drive Components Parts List
Reduction Wheel Drive Additions Components Parts List
Ref #
Part #
Description
GK5903 GK5904
1 GK4219 GK4240 Outer Wheel Disk
2 GK4218 GK4241 Wheel Disk, Rubber
3 GK4217 GK4242 Inner Wheel Weldment
4 S-7329 S-7329 5/16"-18 x 2" HHCS Bolt Zinc Grade 2
5 S-7382 S-7382 5/16"-18 Nylock Nut Zinc Grade 5
6 GK4223 GK4223 Outer Drive Housing Weldment with Bushing
7 GK4211 GK4211 1" I.D. x 1-1/2" O.D. Flat Washer 10 Gauge Zinc
8 GK4234 GK4234 #40 40T Sprocket with Hub
9 GK4215 GK4215 Housing Ring with Grease Zerk
10 GK4233 GK4233 # 40 Double Roller Chain with Link
11 S-4383 S-4383 5/16" x 2-1/4" Rolled Spring Pin
12 GK4210 GK4210 1" I.D. x 1-1/2" O.D. Flat Washer 14 Gauge Zinc
13 GK4213 GK4228 Inner Drive Housing Weldment with Bushing
14 S-7076 S-7076 5/16"-18 x 2-1/2" HHCS Bolt Zinc Grade 5
15 GK4232 GK4233 Bearing, 1" I.D., 2 Hole Flange
16 S-968 S-968 3/8"-16 Serrated Flange Nut Zinc Grade 5
17 GK6526 GK6526 Drive Shaft, with Sprocket and Roll Pin
18 DC-1687 DC-1687 Shipped without Grease Decal
System Part # Description
Complete Drive
6" GK5903 Reduction Wheel Drive, 4:1, Chain
8" and 10" GK5904 Reduction Wheel Drive, 4:1, Chain
Bushing for Drives
6" GK4205 Bushing 1" x 1" x 4-3/8"
8" and 10" GK4206 Bushing 1-1/2" x 1" x 4-3/8"
Hardware for Flight, Bushing and Drive Shaft
6" S-6762 3/8"-16 x 2-1/2" HHCS Bolt Zinc Grade 5
8" and 10" S-8677 3/8"-16 x 3" HHCS Bolt YDP Grade 8
ALL S-8251 3/8"-16 Stover Nut Grade C
Hardware for Shield and Drive Housing
6" S-3727 3/8"-16 x 1-3/4" HHCS Bolt YDP Grade 8
8" and 10" S-8706 3/8"-16 x 1-3/4" HHTB Bolt Zinc Grade 5
ALL S-248 3/8" Flat Washer Zinc
ALL S-7383 3/8" Nylock Nut Zinc Grade 5
