9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells)
67
6", 8" and 10" Bin Flange Parts
Control Pipe
NOTE: All two (2) piece pipes assemble with GC05323; 3/8" NPT x 1.0" pipe connector.
Bin
Size
Center Well Control Pipe (8)
Intermediate Well Control Pipe (9)
Clutch Control Pipe (10)
Part #
Description
6" Part #
8" or 10"
Part #
Description
Part #
Description
15'
GC09110
0.840" O.D. x 7'
GC10360
GC11114
1" O.D. x 5' 1.851"
GK1709 0.840" O.D. x 10'
18'
GC09111
0.840" O.D. x 8' 6"
GC10359
GC11115
1" O.D. x 6' 10.475"
GK1720 0.840" O.D. x 11' 6"
21'
GC09112
0.840" O.D. x 10'
GC10358
GC11117
1" O.D. x 8' 6.824"
GK1730 0.840" O.D. x 13'
24'
GC09113
0.840" O.D. x 11' 6"
GC10357
GC11118
1" O.D. x 9' 8.726"
GK1744 0.840" O.D. x 14' 6"
27'
GC09114
0.840" O.D. x 13'
GC10356
GC11119
1" O.D. x 10' 8.726"
GK1749 0.840" O.D. x 16'
30'
GC09115
0.840" O.D. x 14' 6" GC10355
GC11120
1" O.D. x 11' 8.726"
GK1754 0.840" O.D. x 17' 6"
33'
GC09116
0.840" O.D. x 16'
GC10354
GC11121
1" O.D. x 14' 1.664"
GK1761 0.840" O.D. x 19' 6"
36'
GC09117
0.840" O.D. x 17' 6" GC10353
GC11122
1" O.D. x 515' 4.664"
GK1769 0.840" O.D. x 20' 6"
39'
GC09118
0.840" O.D. x 19'
-
GC11123
1" O.D. x 16' 6.164"
GK1766 0.840" O.D. x 1'
GK1776 0.840" O.D. x 21'
42'
GC09119
0.840" O.D. x 20' 6"
-
GC11124
1" O.D. x 18' 8.226"
GK1784 0.840" O.D. x 2' 6"
GK1776 0.840" O.D. x 21'
48'
GK1776
0.840" O.D. x 21'
-
GC11125
1" O.D. x 21'
GK1718 0.840" O.D. x 5' 6"
GC09075
0.840" O.D. x 2' 6"
GK1776 0.840" O.D. x 21'
