9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells)
63
10" Intermediate Well Parts List
Ref #
Part #
Description
1
GC10131
Intermediate Well Weldment
2
GK1057
10" Half Band
3
GK6762
10" Intermediate Well Gate
4
GK6763
10" Intermediate Well Top Flange
5
GK6714
10" Control Rod Guide
6
GC09006
Control Pipe Clamp with Dimple
7
GC03064
1-1/2" O.D. x 5/8" Nylatron Roller
8
S-2121
1/2" Flat Washer Plated, 9/16" I.D. x 1/10" x 1-3/8" O.D.
9
S-7241
1/8" x 1-1/4" Cotter Pin Zinc Grade 2
10
S-4275
5/16"-18 x 3/4" HHTB Bolt Zinc Grade 5
11
S-3611
5/16"-18 Serrated Flange Nut YDP Grade 2
12
S-1196
5/16"-18 x 1" HHCS Bolt Grade 5
13
S-2741
5/16"-18 x 1-1/2" HHCS Bolt Zinc Grade 5
Tube (14)
Flight (15)
Part #
Description
Part #
Description
GK6921
10" x 24' Bin 12" Well
GK7039
10" x 175-1/4" 24' Bin
GK6922
10" x 27' Bin 12" Well
GK7040
10" x 193-1/4" 27' Bin
GK6923
10" x 30' Bin 12" Well
GK7041
10" x 211-1/4" 30' Bin
GK6924
10" x 33' Bin 12" Well
GK7042
10" x 235-1/4" 33' Bin
GK6925
10" x 36' Bin 12" Well
GK7043
10" x 247-1/4" 36' Bin
GK6926
10" x 39' Bin 12" Well
GK7044
10" x 265-1/4" 39' Bin
GK6927
10" x 42' Bin 12" Well
GK7045
10" x 289-1/4" 42' Bin
GK6928
10" x 48' Bin 12" Well
GK7046
10" x 325-1/4" 48' Bin
