9. Parts List
64 PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells)
6" Bin Flange Parts
6" Bin Flange Parts List
Ref # Part # Description
1 GC10546 6" Top Bin Flange
2 GC10547 6" Bottom Bin Flange
3 GK1619 Clutch Control Rod Position Lock Flange
4 S-3611 5/16"-18 Serrated Flange Nut YDP Grade 2
5 S-2741 5/16"-18 x 1-1/2" HHCS Bolt Zinc Grade 5
6 S-6076 5/16"-18 x 3/4" Carriage Bolt Zinc Grade 2
7 S-275 5/16"-18 x 3/4" HH BIN Bolt YDP Grade 5
8 See Page 67
9 See Page 67
10 See Page 67
11 GC12074 Clutch Control Rod Handle
12 S-8397 5/16" x 1-3/4" Spring Pin
13 GK1726 1/2" Control Rod Clamp
14 S-1937 5/16" Flat Washer Zinc Grade 2
15 S-3611 5/16"-18 Serrated Flange Nut YDP Grade 2
16 GK1206 6" End Cap
17 S-275 5/16"-18 x 3/4" HH BIN Bolt YDP Grade 5
