9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells)
61
8" Intermediate Well Parts List
Ref #
Part #
Description
1
GC10129
8" Intermediate Well Weldment
2
GK1055
8" Half Band
3
GK6759
8" Intermediate Well Gate
4
GK6760
8" Intermediate Well Top Flange
5
GK6711
8" Control Rod Guide
6
GC00174
Control Gate Clamp with Dimple for 6" and 8"
7
GC03064
1-1/2" O.D. x 5/8" Nylatron Roller
8
S-2121
1/2" Flat Washer Plated, 9/16" I.D. x 1/10" x 1-3/8" O.D.
9
S-7241
1/8" x 1-1/4" Cotter Pin Zinc Grade 2
10
S-4275
5/16"-18 x 3/4" HHTB Bolt Zinc Grade 5
11
S-3611
5/16"-18 Serrated Flange Nut YDP Grade 2
12
S-1196
5/16"-18 x 1" HHCS Bolt Grade 5
Tube (14)
Flight (15)
Part #
Description
Part #
Description
GK6899
8" x 15' Bin 12" Well
GK7028
8" x 121-1/4" 15' Bin
GK6900
8" x 18' Bin 12" Well
GK7029
8" x 145-1/4" 18' Bin
GK6901
8" x 21' Bin 12" Well
GK7030
8" x 157-1/4" 21' Bin
GK6902
8" x 24' Bin 12" Well
GK7031
8" x 175-1/4" 24' Bin
GK6903
8" x 27' Bin 12" Well
GK7032
8" x 193-1/4" 27' Bin
GK6904
8" x 30' Bin 12" Well
GK7033
8" x 211-1/4" 30' Bin
GK6905
8" x 33' Bin 12" Well
GK7034
8" x 235-1/4" 33' Bin
GK6906
8" x 36' Bin 12" Well
GK7035
8" x 247-1/4" 36' Bin
GK6907
8" x 39' Bin 12" Well
GK7036
8" x 265-1/4" 39' Bin
GK6908
8" x 42' Bin 12" Well
GK7037
8" x 289-1/4" 42' Bin
GK6909
8" x 48' Bin 12" Well
GK7038
8" x 325-1/2" 48' Bin
