9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells) 57
Center Connection Parts
Center Connection Parts List
Ref # Part # Description
1
GK7129 Center Well Assembly - 6"
GK7130 Center Well Assembly - 8"
GK7131 Center Well Assembly - 10"
2
GK1624 Connecting Band - 6"
GK1677 Connecting Band - 8"
GK1796 Connecting Band - 10"
3 S-2741 5/16"-18 x 1-1/2" HHCS Bolt Zinc Grade 5
4 S-3611 5/16"-18 Serrated Flange Nut YDP Grade 2
5 GK1726 1/2" Control Rod Clamp
6 S-8397 5/16" x 1-3/4" Spring Pin
7 S-6076 5/16"-18 x 3/4" Carriage Bolt Zinc Grade 2
8 S-1937 5/16" Flat Washer Zinc Grade 2
9 S-7149 5/16"-18 x 1-3/4" HHTB Bolt Zinc Grade 5
10 S-7382 5/16"-18 Nylock Nut Zinc Grade 5
11 GK4460 Gearbox Pivot Bracket
12 S-9067 3/8"-16 x 3/4" Serrated Flange Bolt Zinc Grade 5
13
GK6175 Shield Mounting Bracket - 6" and 8"
GK4461 Shield Mounting Bracket - 10"
14 S-10110 1/2"-13 x 1/2" Shoulder Bolt
15 S-8260 1/2"-13 Nylock Nut Zinc Grade 5
