9. Parts List
PNEG-1421 Direct Gear Drive Bin Sweep Auger (with Roller Wells)
59
6" Intermediate Well Parts List
Ref #
Part #
Description
1
GC10126
6" Intermediate Well Weldment
2
GK1053
6" Half Band
3
GK6756
6" Intermediate Well Gate
4
GK6757
6" Intermediate Well Top Flange
5
GK6713
6" Control Rod Guide
6
GC00174
Control Gate Clamp with Dimple for 6" and 8"
7
GC03064
1-1/2" O.D. x 5/8" Nylatron Roller
8
S-2121
1/2" Flat Washer Plated, 9/16" I.D. x 1/10" x 1-3/8" O.D.
9
S-7241
1/8" x 1-1/4" Cotter Pin Zinc Grade 2
10
S-4275
5/16"-18 x 3/4" HHTB Bolt Zinc Grade 5
11
S-3611
5/16"-18 Serrated Flange Nut YDP Grade 2
12
S-1196
5/16"-18 x 1" HHCS Bolt Grade 5
13
S-8999
5/16"-18 x 1/2" HHCS Bolt Zinc Grade 5
Tube (14)
Flight (15)
Part #
Description
Part #
Description
GK6890
6" x 15' Bin 12" Well
GK7020
6" x 121-1/4" 15' Bin
GK6891
6" x 18' Bin 12" Well
GK7021
6" x 145-1/4" 18' Bin
GK6892
6" x 21' Bin 12" Well
GK7022
6" x 157-1/4" 21' Bin
GK6893
6" x 24' Bin 12" Well
GK7023
6" x 175-1/4" 24' Bin
GK6894
6" x 27' Bin 12" Well
GK7024
6" x 193-1/4" 27' Bin
GK6895
6" x 30' Bin 12" Well
GK7025
6" x 211-1/4" 30' Bin
GK6896
6" x 33' Bin 12" Well
GK7026
6" x 235-1/4" 33' Bin
GK6897
6" x 36' Bin 12" Well
GK7027
6" x 247-1/4" 36' Bin
