Modbus specific status
HART device status
Modbus Register Value Description Format
Sub-device
Index
(CMD 84)
30013 30014 AI Primary Variable
(loop current, mA unit) 32-bit floating
point 1
30015 30016 PV Primary Variable
(device-specific unit)
30017 30018 SV Secondary Variable
(device-specific unit)
30019 30020 TV Tertiary Variable
(device-specific unit)
30021 30022 QV Quaternary Variable
(device-specific unit)
30023 – ModStat Modbus Specific Status * 16-bit
unsigned
integer
30024 – DevStat HART Device Status *
30025 30026 AI Primary Variable
(loop current, mA unit) 32-bit floating
point 2
30027 30028 PV Primary Variable
(device-specific unit)
30029 30030 SV Secondary Variable
(device-specific unit)
30031 30032 TV Tertiary Variable
(device-specific unit)
30033 30034 QV Quaternary Variable
(device-specific unit)
30035 – ModStat Modbus Specific Status * 16-bit
unsigned
integer
30036 – DevStat HART Device Status *
* For a detailed description refer to the following tables.
Bit Parameter Description
0x01 (LSB**) Cache validity Set to "1" when the HART Command 3
cache of the device is "empty".
0x02 (LSB**) Identification
ongoing Set to "1" when the Gateway is performing
a device identification procedure.
** LSB = least significant bit
Bit Parameter Description
0x80 Device malfunction The device detected a serious error or
failure that compromises device operation.
0x40 Configuration
changed An operation was performed that changed
the device's configuration.
