Technical data
Measured value display (optional)
Liquid-crystal indication
- in the sensor scalable output of measured values as graph
and as number
- in the external indicating instrument scalable output of measured values as graph
powered by the sensor and as number. Measured value display can be
mounted up to 25 m away from the sensor
Adjustment
- PC and adjustment software VEGA Visual Operating
- adjustment module MINICOM
- VEGA signal conditioning instrument
Accuracy 1) (typical value under reference conditions, all statements relate to the nominal
measuring range, for type 45 relating to a measuring range of 4 m)
Characteristics linear
Accuracy (deviation in characteristics
incl. linearity, repeatability and
hysteresis determined by the
limit point method)
< 0.05 %
Average temperature coefficient
of the zero signal 0.06 %/10 °K
Resolution generally max. 1 mm
Resolution of the output signal 0.005 % or 1 mm
Characteristics 1) (typical values under reference conditions, all statements refer to the nomi-
nal measuring range)
Min. span between
full and empty > 10 mm (recommended > 50 mm)
Frequency 26 GHz technology
Meas. intervals 0.6 s
Beam angle (at -3 dB)
- VEGAPULS 42 22°
optional 18°, 10° and 8° bigger coupling horns, deviating
from standard dimensions
- VEGAPULS 44
DN 50, ANSI 2" 18°
DN 80, ANSI 3" 10°
DN 100, ANSI 4" 8°
DN 150, ANSI 6" 8°
Adjustment time (response time) > 1 s (dependent on the parameter setting)
Influence of the process temperature cannot be measured at 0 bar;
at 5 bar 0.004 %/10 °K;
at 40 bar 0.03 %/10 °K
Influence of the process pressure 0.0265 %/bar
Adjustment time 2) > 1 s (dependent on the parameter setting)
Radar emitted power (average) 0.717 µW
Received average emitted power 3)
- distance 1 m 0.5 … 1.5 nW per cm² (0.5 … 1.5 x 10 -9 W/cm²)
- distance 5 m 0.02 … 0.6 nW per cm²
