10 VEGAPULS 42, 44 and 45 – VBUS
Features
General features
• Measurement preferably of liquids in storage tanks or process vessels with increased
accuracy requirement.
• Measuring range 0 … 4 m, 0 … 10 m or 0 … 20 m.
• Ex approved in Zone 1 (IEC) or Zone 1 (ATEX) classification mark
EEx ia [ia] IIC T6.
• Integrated display of measured values.
Overview
PS42XXE… PS44XXE… PS45XXXE…
Signal output
- VBUS (VEGA-Bus)
• • •
Antenna
- horn antenna
• • –
- pipe antenna 1) 1) •
Process fitting
- G 1½ A; 1½" NPT
• – •
- DN 50; ANSI 2" – • •
- DN 80; ANSI 3" – • •
- DN 100; ANSI 4" – • •
- DN 150; ANSI 6" – • •
Adjustment
- P C
• • •
- adjustment module in the sensor • • •
- adjustment module in external
indicating instrument • • •
- with signal conditioning instrument • • •
Measuring range 0 … 4 m
- ø 40 mm horn 0 … 10 m – (depending on the
- ø 48 mm horn 0 … 15 m 0 … 15 m tube length)
- ø 75 mm horn 0 … 20 m 0 … 20 m
- ø 95 mm horn 0 … 20 m 0 … 20 m
Types and versions
1) When mounting on a standpipe or bypass tube, a pipe antenna is created. The tube inner diameter should be
between 40 mm and 80 mm.
