VEGASON 51 V … 53 V 55
• Click to "Show echo curve"
The echo curve and the false echo marking is
displayed.
• Quit the menu with "Quit".
You are again in the menu window " Sensor
optimisation".
With the menu point "
Reset" you reset all
options of the menu " Sensor optimisation" to
basic adjustment.
• Quit the menu window "Sensor
optimisation" with "Quit" and with
"Quit" the menu window "
Sensor choice for
sensor optimisation"
You are then in the menu window " Instrument
data parameter adjustment".
• Click in the window "Instrument data pa-
rameter adjustment" to "Meas. Loop Data".
• Click to "Application", to "Input No. A" and
"VEGAMET", to get detailled information on
your measuring system in the information
windows.
Set-up - Adjustment with PC on VEGAMET
