Mounting boss, Material cones – VEGA VEGASON 51V…53V User Manual
Page 29
VEGASON 51 V … 53 V
29
,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
Mounting and installation
-
Measurement of solids
Mounting boss
VEGASON 51 or 52 on the mounting boss. The socket
axis should point to the product surface
VEGASON 52 on mounting boss
Material cones
Large material cones are detected with sev-
eral instruments which you can fasten on
lifting beams.
Transducer on lifting beam above material cone
Reference pane
Min. distance
