H8035/H8036 INSTALLATION GUIDE
MODBUS REGISTER ADDRESSING
This table lists the addressed assigned to each data point. Registers are read MostSignificant Byte (MSB) first. 32 bit floating point values are encoded per IEEE Standard 754.
For floating point format variables, each data point appears twice because two 16-bit addresses are required to hold a 32-bit float value. The 16 bit Most Significant Word
(MSW) is in the lower address of the register pair, while the least Significant Word (LSW) is in the upper address.
Modbus RTU function codes supported: 3=read holding registers; 6=preset single register; 17=report Slave I.D.
Quick Reference of the Most Common Data Points
Address Typical
Offset
Units Description Integer:
multiplier required
Float:
upper 16 bits
Float:
lower 16 bits
40001 0 kWh Energy Consumption, LSW X
40002 1 kWh Energy Consumption, MSW X
40003 2 kW Real Power X
40257 --- kWh Energy Consumption X
40258 kWh Energy Consumption X
40259 0 kWh Energy Consumption (same 40257) X
40260 kWh Energy Consumption (same 40258) X
40261 2 kW Real Power X
40262 kW Real Power X
Complete Listing of Data Points
Address Typical
Offset
Units Description Integer:
multiplier required
Float:
upper 16 bits
Float:
lower 16 bits
40001 0 kWh Energy Consumption, LSW X
40002 1 kWh Energy Consumption, MSW X
40003 2 kW Real Power X
40004 3 kVAR Reactive Power X
40005 4 kVA Apparent Power X
40006 5 --- Power Factor X
40007 6 Volts Voltage, line to line X
40008 7 Volts Voltage, line to neutral X
40009 8 Amps Current X
40010 9 kW Real Power, Phase A X
40011 10 kW Real Power, Phase B X
40012 11 kW Real Power, Phase C X
40013 12 --- Power Factor, phase A X
40014 13 --- Power Factor, phase B X
40015 14 --- Power Factor, phase C X
40016 15 Volts Voltage, phase A-B X
40017 16 Volts Voltage, phase B-C X
40018 17 Volts Voltage, phase A-C X
40019 18 Volts Voltage, phase A-N X
40020 19 Volts Voltage, phase B-N X
40021 20 Volts Voltage, phase C-N X
40022 21 Amps Current, phase A X
40023 22 Amps Current, phase B X
40024 23 Amps Current, phase C X
40025 24 kW Average Real Power X
40026 25 kW Minimum Real Power X
40027 26 kW Maximum Real Power X
40257 --- kWh Energy Consumption X
40258 kWh Energy Consumption X
40259 0 kWh Energy Consumption (same 40257) X
40260 kWh Energy Consumption (same 40258) X
40261 2 kW Real Power X
40262 kW Real Power X
