Section 4
Using the TROY Printer Utility
Security Printing Solutions User’s Guide -- Document #50-70376-001 Rev. D
4-17
Selecting Data
Capture Fonts for
Audit Reports
and TROYmark
™
(cont.)
5. After all the desired check fields have been
defined, click on Create Metrics. Type in
the desired file name or use TROY (default)
for the data capture metrics file in the File
Name box, and then click on Save. You
may create as many data capture font set
configurations (metrics files) as needed for
your check printing requirements. The
system will automatically generate the
metrics file required to capture the selected
check data for the TROYmark
™
background
image or the TROY audit report.
6. After the data capture metrics file is created
by the TROY Printer Utility, see Section 5 –
Installing the TROY Support Files
, and
follow the steps for installing the metrics
file on the host computer.
NOTE: If more than one data capture metrics file is installed, the previously installed metrics file will automatically
be overwritten. TROY recommends using only one data capture metrics file for each computer in your MICR
printing network.
Save File
File name:
TROY
Open as read-only
Save in:
UserData
Save as type:
Save
Cancel
Printer Cartridge Metrics (*.pcm)
