Section 4 Using the TROY Printer Utility
Security Printing Solutions User’s Guide -- Document #50-70376-001 Rev. D
4-14
Re-Mapping
Printer Paper
Trays (cont.) The following table contains common tray mapping numbers for TROY printers. Due to the Hewlett-Packard
tray assignment scheme, the actual tray number embossed on the paper tray(s) of your TROY printer may not
correspond with the factory tray assignment numbers listed in the table below (e.g., physical tray #2 has a factory
tray assignment number of 3, etc.). Always use the factory tray assignment numbers (listed in the table below)
when re-mapping your printer paper trays using the TROY Printer Utility.
Factory Tray Assignment
Numbers
Physical Paper Source (Media)
2300
Printer
4200
Printer
4300
Printer
Paper Tray 1 (manual feed) 4 4 4
Paper Tray 2 1 1 1
Paper Tray 3 (standard on “T” model printers) 5 5 5
Paper Tray 4 (Optional item for all printers) N/A 8 8
