Spicer DRIVELINE COMPONENTS CATALOG FLANGE & END YOKE APPLICATIONS - Manual (Page 94)

*(C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange))
93
TANDEM
AXLES
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Tandem Axles — Spicer ®
454 (Continued)
2 SPL140 2.024-39 3.000 4.940 EY 140-4-361-1
2 SPL170 2.024-39 2.625 5.266 EY 170-4-211-1
2 SPL170 2.024-39 2.625 5.266 EY 170-4-221-1X
2 SPL170 2.024-39 2.625 6.500 EY 170-4-231-1
High angle yoke
2 SPL170 2.024-39 2.625 6.500 EY 170-4-241-1X
High angle yoke
2 SPL170 2.024-39 2.625 5.750 EY 5001768
2 1610 2.024-39 2.625 6.000 EY 5-4-8301
High angle yoke
2 1610 2.024-39 2.625 6.000 EY 5-4-9271X
High angle yoke
2 1710 2.024-39 2.625 6.125 EY 6-4-8431
2 1710 2.024-39 2.625 6.125 EY 6-4-8431-1
2 1710 2.024-39 2.625 5.250 EY 6-4-8441
2 1710 2.024-39 2.625 5.250 EY 6-4-8441-1
2 1710 2.024-39 2.625 6.125 EY 6-4-9001-1X
2 1710 2.024-39 2.625 6.125 EY 6-4-9001X
2 1710 2.024-39 2.625 5.250 EY 6-4-9041-1X
2 1710 2.024-39 2.625 5.250 EY 6-4-9041X
3 SPL140 2.024-39 3.000 4.940 EY 140-4-1151-1
3 SPL140 2.024-39 3.000 4.940 EY 140-4-1161-1X
3 SPL140 2.024-39 3.000 4.940 EY 140-4-361-1
3 SPL140 2.024-39 3.000 4.940 EY 140-4-371-1X
3 SPL170 2.024-39 3.000 6.240 EY 170-4-1621-1
3 SPL170 2.024-39 3.000 6.240 EY 170-4-1631-1X
3 SPL170 2.024-39 2.625 6.500 EY 170-4-1641-1
3 SPL170 2.024-39 2.625 6.500 EY 170-4-1651-1X
3 SPL170 2.274-44 3.000 5.270 EY 170-4-201-1X
3 SPL170 2.024-39 3.000 5.156 EY 170-4-251-1
3 SPL170 2.024-39 3.000 5.156 EY 170-4-261-1X
3 SPL170 2.024-39 3.000 6.240 EY 170-4-271-1
High angle yoke
3 SPL170 2.024-39 3.000 6.240 EY 170-4-281-1X
High angle yoke
3 SPL170 2.024-39 3.000 5.540 EY 5001766
3 SPL250 2.274-44 3.000 5.490 EY 250-4-81-1X
3 SPL90 2.024-39 3.000 4.750 EY 90-4-241-1
3 SPL90 2.024-39 3.000 4.750 EY 90-4-251-1X
3 1480 2.024-39 3.000 4.344 EY 3-4-13071-1
3 1480 2.024-39 3.000 4.344 EY 3-4-13081-1X
3 1550 2.024-39 3.000 4.281 EY 4-4-7561-1
3 1550 2.024-39 3.000 4.281 EY 4-4-7571-1X
3 1610 2.024-39 3.000 6.000 EY 5-4-8261
High angle yoke
3 1610 2.024-39 3.000 6.000 EY 5-4-8261-1
High angle yoke
3 1610 2.024-39 3.000 4.875 EY 5-4-9221-1
3 1610 2.024-39 3.000 4.875 EY 5-4-9231-1X
3 1610 2.024-39 3.000 6.000 EY 5-4-9241-1X
High angle yoke
3 1610 2.024-39 3.000 6.000 EY 5-4-9241X
High angle yoke
3 1710 2.024-39 3.000 6.125 EY 6-4-8411-1
3 1710 2.024-39 3.000 5.250 EY 6-4-8421
3 1710 2.024-39 3.000 5.250 EY 6-4-8421-1
3 1710 2.024-39 3.000 6.125 EY 6-4-8991-1X
3 1710 2.024-39 3.000 6.125 EY 6-4-8991X
High angle yoke
3 1710 2.024-39 3.000 5.250 EY 6-4-9031-1X
3 1710 2.024-39 3.000 5.250 EY 6-4-9031X
460
1 1610 2.422-18 3.375 6.125 EY 5-4-5491-1X
1 1710 2.422-18 3.375 5.250 EY 6-4-3161
1 1710 2.422-18 3.375 5.812 EY 6-4-4581
1 1710 2.422-18 3.375 5.812 EY 6-4-4581-1
1 1710 2.422-18 3.375 5.812 EY 6-4-4751-1X
1 1710 2.422-18 3.375 5.812 EY 6-4-4751X
1 1760 2.422-18 3.375 6.000 EY 6.3-4-241-1X
1 1760 2.422-18 3.375 6.000 EY 6.3-4-241X
1 1810 2.422-18 3.375 5.812 EY 6.5-4-1991
1 1810 2.422-18 3.375 5.812 EY 6.5-4-1991-1
1 1810 2.422-18 3.375 5.812 EY 6.5-4-2361-1X
1 1810 2.422-18 3.375 5.812 EY 6.5-4-2361X
2 1610 2.149-16 2.938 6.250 EY 5-4-5161-1X
2 1610 2.149-16 2.938 6.250 EY 5-4-5161X
2 1610 2.149-16 2.938 6.500 EY 5-4-5511X
High angle yoke
2 1710 2.149-16 2.938 5.500 EY 6-4-4171-1X
2 1710 2.149-16 2.938 5.500 EY 6-4-4171X
2 1710 2.149-16 2.938 6.625 EY 6-4-4591
High angle yoke
2 1710 2.149-16 2.938 6.625 EY 6-4-5481X
High angle yoke
2 1760 2.149-16 2.938 5.812 EY 6.3-4-141-1
2 1760 2.149-16 2.938 5.812 EY 6.3-4-251-1X
2 1760 2.149-16 2.938 5.812 EY 6.3-4-251X
2 1810 2.422-18 3.375 5.812 EY 6.5-4-1991
2 1810 2.149-16 2.938 5.812 EY 6.5-4-2291-1
2 1810 2.149-16 2.938 5.812 EY 6.5-4-2401-1X
2 1810 2.149-16 2.938 5.812 EY 6.5-4-2401X
3 1610 2.149-16 2.938 6.250 EY 5-4-5161-1X
3 1610 2.149-16 2.938 6.250 EY 5-4-5161X
3 1610 2.149-16 2.938 6.500 EY 5-4-5511X
High angle yoke
3 1710 2.149-16 2.938 5.500 EY 6-4-4171-1X
3 1710 2.149-16 2.938 5.500 EY 6-4-4171X
3 1710 2.149-16 2.938 6.625 EY 6-4-5481X
High angle yoke
3 1760 2.149-16 2.938 5.812 EY 6.3-4-141-1
3 1760 2.149-16 2.938 5.812 EY 6.3-4-251-1X
3 1760 2.149-16 2.938 5.812 EY 6.3-4-251X
3 1810 2.422-18 3.375 5.812 EY 6.5-4-1991
3 1810 2.149-16 2.938 5.812 EY 6.5-4-2291-1
3 1810 2.149-16 2.938 5.812 EY 6.5-4-2401-1X
3 1810 2.149-16 2.938 5.812 EY 6.5-4-2401X
461
1 SPL140 2.390-46 3.375 6.440 EY 140-4-381-1
1 SPL140 2.390-46 3.375 6.440 EY 140-4-391-1X
1 SPL170 2.390-46 3.375 6.531 EY 170-4-291-1
1 SPL170 2.390-46 3.375 6.531 EY 170-4-301-1X
1 SPL250 2.390-46 3.375 6.760 EY 250-4-101-1X
1 SPL250 2.390-46 3.375 6.760 EY 250-4-91-1
1 1550 2.143-41 2.938 4.500 EY 4-4-5581-1
1 1610 2.143-41 2.938 5.250 EY 5-4-7271-1
1 1610 2.143-41 2.938 6.000 EY 5-4-7561
1 1610 2.143-41 2.938 6.000 EY 5-4-7561-1
1 1610 2.143-41 2.938 5.250 EY 5-4-9111-1X
1 1610 2.143-41 2.938 6.000 EY 5-4-9121-1X
Continued on next page
