*(C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange))
69
TANDEM
AXLES
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Tandem Axles — Meritor/Rockwell
SL-100 (Continued)
3 1710 2.024-39 3.000 5.156 EY 6-4-6401
3 1710 2.024-39 3.000 5.156 EY 6-4-6421-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-6421X
3 1710 2.024-39 3.000 5.156 EY 6-4-7621-1
3 1710 2.024-39 3.000 5.156 EY 6-4-7631-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-7641-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-8601-1X
3 1760 2.024-39 3.000 5.188 EY 6.3-4-1141-1X
3 1760 2.024-39 3.000 5.188 EY 6.3-4-531
3 1760 2.024-39 3.000 5.188 EY 6.3-4-531-1
SL-100P
1 1610 2.024-39 3.000 5.531 EY 5-4-6281X
1 1610 2.024-39 3.000 4.875 EY 5-4-6431-1X
1 1610 2.024-39 3.000 4.875 EY 5-4-6431X
1 1710 2.024-39 3.000 6.250 EY 6-4-6381X
High angle yoke
1 1710 2.024-39 3.000 5.156 EY 6-4-6401
1 1710 2.024-39 3.000 5.156 EY 6-4-6401-1
1 1710 2.024-39 3.000 5.156 EY 6-4-6411X
1 1710 2.024-39 3.000 5.156 EY 6-4-7621-1
1 1710 2.024-39 3.000 5.156 EY 6-4-7631-1X
1 1760 2.024-39 3.000 5.188 EY 6.3-4-531
1 1760 2.024-39 3.000 5.188 EY 6.3-4-531-1
1 1760 2.024-39 3.000 5.188 EY 6.3-4-541-1X
1 1760 2.024-39 3.000 5.188 EY 6.3-4-541X
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3371
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3371-1
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3381-1X
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3381X
2 1610 2.250-10 3.500 3.625 CF 5-1-6331
2 1610 1.774-34 2.500 6.062 EY 5-4-6251
High angle yoke
2 1610 1.774-34 2.500 5.438 EY 5-4-6261
2 1610 1.998-38 2.750 4.125 EY 5-4-6321
2 1710 1.774-34 2.500 5.969 EY 6-4-6321
High angle yoke
2 1710 1.774-34 2.500 4.875 EY 6-4-6331
3 1610 2.024-39 3.000 5.531 EY 5-4-6281X
3 1610 2.024-39 3.000 6.219 EY 5-4-6291X
High angle yoke
3 1610 2.024-39 3.000 4.875 EY 5-4-6431-1X
3 1610 2.024-39 3.000 4.875 EY 5-4-6431X
3 1610 2.024-39 3.000 4.875 EY 5-4-6441-1X
3 1710 2.024-39 3.000 6.250 EY 6-4-6391X
High angle yoke
3 1710 2.024-39 3.000 5.156 EY 6-4-6421-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-6421X
3 1710 2.024-39 3.000 5.156 EY 6-4-7631-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-7641-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-8601-1X
3 1760 2.024-39 3.000 5.188 EY 6.3-4-1141-1X
3 1760 2.024-39 3.000 5.188 EY 6.3-4-541X
SLD, SLDD
1 1480 1.875-10 2.750 4.406 EY 3-4-6671-1X
1 1550 1.875-10 2.750 4.406 EY 4-4-1941
1 1610 1.875-10 2.750 5.000 EY 5-4-2501
2 1480 1.875-10 2.750 4.406 EY 3-4-6671-1X
2 1550 1.875-10 2.750 4.406 EY 4-4-1941
2 1610 1.875-10 2.750 5.000 EY 5-4-2501
SLD, SLDD (Continued)
3 1480 1.875-10 2.750 4.406 EY 3-4-6671-1X
3 1550 1.875-10 2.750 4.406 EY 4-4-1941
3 1610 1.875-10 2.750 5.000 EY 5-4-2501
SLHD
1 1610 2.000-10 2.938 5.188 EY 5-4-5131X
1 1710 2.000-10 2.938 5.188 EY 6-4-3241
1 1760 2.000-10 2.938 5.375 EY 6.3-4-181X
SLHP
1 1760 2.024-39 3.000 5.188 EY 6.3-4-191X
SPRC-1357
1 1610 2.024-39 3.000 5.531 EY 5-4-6281X
1 1610 2.024-39 3.000 4.875 EY 5-4-6431-1X
1 1610 2.024-39 3.000 4.875 EY 5-4-6431X
1 1710 2.024-39 3.000 6.250 EY 6-4-6381X
High angle yoke
1 1710 2.024-39 3.000 5.156 EY 6-4-6411X
1 1710 2.024-39 3.000 5.156 EY 6-4-7631-1X
1 1760 2.024-39 3.000 5.188 EY 6.3-4-541-1X
1 1760 2.024-39 3.000 5.188 EY 6.3-4-541X
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3381-1X
1 1810 2.024-39 3.000 5.190 EY 6.5-4-3381X
2 1610 2.250-10 3.500 3.625 CF 5-1-6331
2 1610 1.774-34 2.500 6.062 EY 5-4-6251
High angle yoke
2 1610 1.774-34 2.500 5.438 EY 5-4-6261
2 1710 1.774-34 2.500 5.969 EY 6-4-6321
High angle yoke
2 1710 1.774-34 2.500 4.875 EY 6-4-6331
3 1610 2.024-39 3.000 5.531 EY 5-4-6281X
3 1610 2.024-39 3.000 6.219 EY 5-4-6291X
High angle yoke
3 1610 2.024-39 3.000 4.875 EY 5-4-6431-1X
3 1610 2.024-39 3.000 4.875 EY 5-4-6431X
3 1610 2.024-39 3.000 4.875 EY 5-4-6441-1X
3 1710 2.024-39 3.000 6.250 EY 6-4-6391X
High angle yoke
3 1710 2.024-39 3.000 5.156 EY 6-4-6421-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-6421X
3 1710 2.024-39 3.000 5.156 EY 6-4-7631-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-7641-1X
3 1710 2.024-39 3.000 5.156 EY 6-4-8601-1X
3 1760 2.024-39 3.000 5.188 EY 6.3-4-541X
SPR450
2 1710 1.960-10 2.750 5.250 EY 6-4-3221
3 1710 1.960-10 2.750 5.250 EY 6-4-3221
SQ-100
1 SPL140 2.024-39 3.000 5.680 EY 140-4-211-1
1 SPL170 2.024-39 3.000 5.090 EY 170-4-641-1
1 SPL170 2.024-39 3.000 5.090 EY 170-4-681-1X
1 1610 2.024-39 3.000 4.875 EY 5-4-6421
1 1610 2.024-39 3.000 4.875 EY 5-4-6421-1
1 1610 2.024-39 3.000 4.875 EY 5-4-6431-1X
1 1610 2.024-39 3.000 4.875 EY 5-4-6431X
1 1710 2.024-39 3.000 6.250 EY 6-4-6371
High angle yoke
1 1710 2.024-39 3.000 6.250 EY 6-4-6371-1
High angle yoke
Continued on next page
