*C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange)
•Hub machined for spedometer gear
103
MAIN TRANSMISSIONS
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos
Series
Spline
Data
Hub
Dia
*C/L to
End of
Hub
End Fitting
Part Number
Pos
Series
Spline
Data
Hub
Dia
*C/L to
End of
Hub
End Fitting
Part Number
Main Transmissions — Allison
AT-542 (Continued)
1
1480 1.790-34 2.562 5.125 EY 3-4-9241-1X
Attaching hardware by OEM
1
1550 1.790-34 2.562 5.156 EY 4-4-4791-1
1
1550 1.790-34 2.562 5.156 EY 4-4-4801-1X
1
1610 1.790-34 2.562 5.312 EY 5-4-7781-1
Contains plug/washer #231059
1
1610 1.790-34 2.562 5.312 EY 5-4-8061-1X
Contains plug/washer #231059
AT-543
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4471
Assembly includes plug 231059 and 4 studs 231016
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4481X
Can be used w/brake
Assembly includes plug 231059 and 4 studs 231016
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4491
Assembly includes plug 231059
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4501X
Assembly includes plug 231059
1 1610/SPL90 1.790-34 2.562 3.719 CF 90-1-11
Assembly includes plug 231059 and eight 6-73-725 bolts
1 1610/SPL90 1.790-34 2.562 3.719 CF 90-1-21X
Assembly includes plug 231059 and eight 6-73-725 bolts
1
SPL90 1.790-34 2.562 5.625 EY 90-4-461-1
Contains plug/washer #231059
1
SPL90 1.790-34 2.562 5.625 EY 90-4-501-1X
Contains plug/washer #231059
1
1480 1.790-34 2.567 4.885 EY 3-4-11551-1
Flanged end yoke, strap kit not furnished by Dana
1
1480 1.790-34 2.567 4.885 EY 3-4-11621-1X
Flanged end yoke, strap kit not furnished by Dana
1
1480 1.790-34 2.562 5.125 EY 3-4-9231-1
Attaching hardware by OEM
1
1480 1.790-34 2.562 5.125 EY 3-4-9241-1X
Attaching hardware by OEM
1
1480 1.790-34 2.562 5.125 EY 3-4-9241-2X
Attaching hardware by OEM
1
1550 1.790-34 2.562 5.156 EY 4-4-4791-1
1
1550 1.790-34 2.562 5.156 EY 4-4-4801-1X
1
1610 1.790-34 2.567 5.310 EY 5-4-5231X
Contains plug/washer #231059
1
1610 1.790-34 2.562 5.312 EY 5-4-7781-1
Contains plug/washer #231059
1
1610 1.790-34 2.562 5.312 EY 5-4-8061-1X
Contains plug/washer #231059
AT-545
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4471
Assembly includes plug 231059 and 4 studs 231016
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4481X
Can be used w/brake
Assembly includes plug 231059 and 4 studs 231016
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4491
Assembly includes plug 231059
1 1480/1550 1.790-34 2.562 3.344 CF 4-1-4501X
Assembly includes plug 231059
1 1610/SPL90 1.790-34 2.562 3.719 CF 90-1-11
Can be used w/brake
Assembly includes plug 231059 and eight 6-73-725 bolts
1 1610/SPL90 1.790-34 2.562 3.719 CF 90-1-21X
Can be used w/brake
Assembly includes plug 231059 and eight 6-73-725 bolts
1
SPL55 1.790-34 2.564 4.870 EY 5001480
Contains plug/washer #231059
AT-545 (Continued)
1
SPL55 1.790-34 2.564 4.870 EY 55-4-101-1X
For 9" x 3" Brake
1
SPL55 1.790-34 2.564 4.870 EY 55-4-91-1
For 9" x 3" Brake
1
SPL90 1.790-34 2.562 5.625 EY 90-4-461-1
Contains plug/washer #231059
1
SPL90 1.790-34 2.562 5.625 EY 90-4-501-1X
Contains plug/washer #231059
1
1480 1.790-34 2.567 4.885 EY 3-4-11551-1
Flanged end yoke, strap kit not furnished by Dana
1
1480 1.790-34 2.567 4.885 EY 3-4-11621-1X
Flanged end yoke, strap kit not furnished by Dana
1
1480 1.790-34 2.562 5.125 EY 3-4-9231-1
Attaching hardware by OEM
1
1480 1.790-34 2.562 5.125 EY 3-4-9241-1X
Attaching hardware by OEM
1
1480 1.790-34 2.562 5.125 EY 3-4-9241-2X
Attaching hardware by OEM
1
1550 1.790-34 2.562 5.156 EY 4-4-4791-1
1
1550 1.790-34 2.562 5.156 EY 4-4-4801-1X
1
1610 1.790-34 2.567 5.310 EY 5-4-5231X
Contains plug/washer #231059
1
1610 1.790-34 2.562 5.312 EY 5-4-7781-1
Contains plug/washer #231059
1
1610 1.790-34 2.562 5.312 EY 5-4-8061-1X
Contains plug/washer #231059
B-300, B-400
1
SPL140 2.178-43 3.539 5.100 EY 140-4-761-1
1
SPL170 2.178-43 3.540 5.340 EY 170-4-1081-1
1
SPL90 2.178-43 3.547 4.625 EY 90-4-791-1
1
1610 2.178-43 3.531 5.406 EY 5-4-9141
1
1610 2.178-43 3.531 5.406 EY 5-4-9141-1
1
1710 2.178-43 3.539 4.875 EY 6-4-9221-1
1
1760 2.178-43 3.539 5.500 EY 6.3-4-1591-1
CLBT-5000
1
1610 2.359-18 3.000 5.219 EY 5-4-2341
CLBT-5961, CLBT-5962
1
1610 1.962-10 3.000 4.750 EY 5-4-2531
CLBT-6000
1
1610 2.359-18 3.000 5.219 EY 5-4-2341
CLBT-6061, CLBT-6062
1
1610 1.962-10 3.000 4.750 EY 5-4-2531
CLBT-7000
1
1610 2.359-18 3.000 5.219 EY 5-4-2341
CLBT-750
1
1810 2.560-20 3.500 4.000 CF 6.5-1-2161
1
1810 2.560-20 3.500 6.125 EY 6.5-4-3361
1
1810 2.560-20 3.500 6.125 EY 6.5-4-3361-1
CLT-5000, CLT-6000
1
1610 2.359-18 3.000 5.219 EY 5-4-2341
CLT-700
1
1810 2.560-20 3.500 4.000 CF 6.5-1-2161
1
1810 2.560-20 3.500 6.125 EY 6.5-4-3361
1
1810 2.560-20 3.500 6.125 EY 6.5-4-3361-1
CLT-7000, CLT-750
1
1610 2.359-18 3.000 5.219 EY 5-4-2341
CLT-750HD
1
1810 2.560-20 3.500 4.000 CF 6.5-1-2161
1
1810 2.560-20 3.500 6.125 EY 6.5-4-3361
