*(C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange))
89
TANDEM
AXLES
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Pos Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Tandem Axles — Spicer ®
402 (Continued)
2 1710 1.790-34 2.625 6.312 EY 6-4-8001-1
High angle yoke
2 1710 1.790-34 2.625 5.438 EY 6-4-8081
2 1710 1.790-34 2.625 5.438 EY 6-4-8081-1
2 1710 1.790-34 2.625 6.312 EY 6-4-8521-1X
High angle yoke
3 SPL170 2.024-39 2.625 4.938 EY 170-4-151-1
3 SPL170 2.024-39 2.625 4.938 EY 170-4-161-1X
3 SPL170 2.024-39 2.625 6.016 EY 170-4-171-1
High angle yoke
3 SPL170 2.024-39 2.625 6.016 EY 170-4-181-1X
High angle yoke
3 1480 2.024-39 2.625 4.344 EY 3-4-13051-1
3 1480 2.024-39 2.625 4.344 EY 3-4-13061-1X
3 1550 2.024-39 2.625 4.266 EY 4-4-6471-1
3 1550 2.024-39 2.625 4.266 EY 4-4-7551-1X
3 1610 2.024-39 2.625 6.000 EY 5-4-5971X
High angle yoke
3 1610 2.024-39 2.625 5.312 EY 5-4-5991X
3 1610 2.024-39 2.625 5.312 EY 5-4-7971
3 1610 2.024-39 2.625 5.312 EY 5-4-7971-1
3 1610 2.024-39 2.625 6.000 EY 5-4-7991
High angle yoke
3 1610 2.024-39 2.625 6.000 EY 5-4-8421X
High angle yoke
3 1710 2.024-39 2.625 5.250 EY 6-4-6001X
.250 deep spline chamfer
3 1710 2.024-39 2.625 6.125 EY 6-4-6021X
High angle yoke; .250 deep spline chamfer
3 1710 2.024-39 2.625 6.125 EY 6-4-7981
High angle yoke
3 1710 2.024-39 2.625 6.125 EY 6-4-7981-1
High angle yoke
3 1710 2.024-39 2.625 5.250 EY 6-4-7991
3 1710 2.024-39 2.625 5.250 EY 6-4-7991-1
3 1710 2.024-39 2.625 5.250 EY 6-4-8531-1X
3 1710 2.024-39 2.625 5.250 EY 6-4-8531X
3 1710 2.024-39 2.625 6.125 EY 6-4-8541-1X
High angle yoke
3 1710 2.024-39 2.625 6.125 EY 6-4-8541X
High angle yoke
404
1 SPL140 2.274-44 3.000 5.160 EY 140-4-1261-1
1 SPL140 2.274-44 3.000 5.160 EY 140-4-1271-1X
1 SPL140 2.274-44 3.000 2.160 EY 140-4-321-1
Metric flanged yoke
1 SPL140 2.274-44 3.000 2.160 EY 140-4-331-1X
Metric flanged yoke
1 SPL170 2.274-44 3.000 5.270 EY 170-4-191-1
1 SPL170 2.274-44 3.000 5.270 EY 170-4-201-1X
1 SPL250 2.274-44 3.000 5.490 EY 250-4-71-1
1 SPL250 2.274-44 3.000 5.490 EY 250-4-81-1X
1 1610 2.274-44 3.000 5.000 EY 5-4-8311-1
1 1610 2.274-44 3.000 5.000 EY 5-4-9261-1X
1 1710 2.274-44 3.000 5.190 EY 6-4-8451
1 1710 2.274-44 3.000 5.190 EY 6-4-8451-1
1 1710 2.274-44 3.000 5.190 EY 6-4-8981-1X
1 1710 2.274-44 3.000 5.190 EY 6-4-8981X
1 1760 2.274-44 3.000 5.250 EY 6.3-4-1411
1 1760 2.274-44 3.000 5.250 EY 6.3-4-1411-1
404 (Continued)
1 1760 2.274-44 3.000 5.250 EY 6.3-4-5221-1X
1 1760 2.274-44 3.000 5.250 EY 6.3-4-5221X
1 1810 2.274-44 3.000 5.250 EY 6.5-4-4311
1 1810 2.274-44 3.000 5.250 EY 6.5-4-4311-1
1 1810 2.274-44 3.000 5.250 EY 6.5-4-4571-1X
1 1810 2.274-44 3.000 5.250 EY 6.5-4-4571X
2 SPL140 2.024-39 3.000 4.940 EY 140-4-361-1
2 SPL170 2.024-39 2.625 5.266 EY 170-4-211-1
2 SPL170 2.024-39 2.625 5.266 EY 170-4-221-1X
2 SPL170 2.024-39 2.625 6.500 EY 170-4-231-1
High angle yoke
2 SPL170 2.024-39 2.625 6.500 EY 170-4-241-1X
High angle yoke
2 SPL170 2.024-39 2.625 5.750 EY 5001768
2 1610 2.024-39 2.625 6.000 EY 5-4-8301
High angle yoke
2 1610 2.024-39 2.625 6.000 EY 5-4-9271X
High angle yoke
2 1710 2.024-39 2.625 6.125 EY 6-4-8431
2 1710 2.024-39 2.625 6.125 EY 6-4-8431-1
2 1710 2.024-39 2.625 5.250 EY 6-4-8441
2 1710 2.024-39 2.625 5.250 EY 6-4-8441-1
2 1710 2.024-39 2.625 6.125 EY 6-4-9001-1X
2 1710 2.024-39 2.625 6.125 EY 6-4-9001X
2 1710 2.024-39 2.625 5.250 EY 6-4-9041-1X
2 1710 2.024-39 2.625 5.250 EY 6-4-9041X
3 SPL100 2.024-39 3.000 7.295 EY 100-4-1361-1
Flanged end yoke
3 SPL100 2.024-39 3.000 7.295 EY 100-4-1371-1X
Flanged end yoke
3 SPL140 2.024-39 3.000 4.940 EY 140-4-1151-1
3 SPL140 2.024-39 3.000 4.940 EY 140-4-1161-1X
3 SPL140 2.274-44 3.000 2.160 EY 140-4-331-1X
Metric flanged yoke
3 SPL140 2.024-39 3.000 4.940 EY 140-4-361-1
3 SPL140 2.024-39 3.000 4.940 EY 140-4-371-1X
3 SPL170 2.024-39 3.000 6.240 EY 170-4-1621-1
3 SPL170 2.024-39 3.000 6.240 EY 170-4-1631-1X
3 SPL170 2.024-39 2.625 6.500 EY 170-4-1641-1
3 SPL170 2.024-39 2.625 6.500 EY 170-4-1651-1X
3 SPL170 2.274-44 3.000 5.270 EY 170-4-201-1X
3 SPL170 2.024-39 3.000 5.156 EY 170-4-251-1
3 SPL170 2.024-39 3.000 5.156 EY 170-4-261-1X
3 SPL170 2.024-39 3.000 6.240 EY 170-4-271-1
High angle yoke
3 SPL170 2.024-39 3.000 6.240 EY 170-4-281-1X
High angle yoke
3 SPL170 2.024-39 3.000 5.540 EY 5001766
3 SPL90 2.024-39 3.000 4.750 EY 90-4-241-1
3 SPL90 2.024-39 3.000 4.750 EY 90-4-251-1X
3 1480 2.024-39 3.000 4.344 EY 3-4-13071-1
3 1480 2.024-39 3.000 4.344 EY 3-4-13081-1X
3 1550 2.024-39 3.000 4.281 EY 4-4-7561-1
3 1550 2.024-39 3.000 4.281 EY 4-4-7571-1X
3 1610 2.024-39 3.000 6.000 EY 5-4-8261
High angle yoke
3 1610 2.024-39 3.000 6.000 EY 5-4-8261-1
High angle yoke
3 1610 2.024-39 3.000 4.875 EY 5-4-9221-1
Continued on next page
