*(C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange))
80
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos
Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Pos
Series
Spline
Data
Hub
Dia
* to
End of
Hub
End Fitting
Part Number
Important: See Safety Information in General Information Section (J300P-GI)
S400 (Continued)
2
SPL170 2.024-39 3.000 6.500 EY 170-4-831-1
High angle yoke
2
1610 2.024-39 3.000 5.594 EY 5-4-9351-1
2
1710 2.024-39 3.000 6.120 EY 6-4-9281-1
2
1710 2.024-39 3.000 5.438 EY 6-4-9411-1
3
SPL170 2.024-39 3.000 6.250 EY 170-4-801-1
High angle yoke
3
SPL170 2.024-39 3.000 6.250 EY 170-4-811-1X
High angle yoke
3
SPL170 2.024-39 3.000 5.031 EY 170-4-841-1
3
SPL170 2.024-39 3.000 5.031 EY 170-4-861-1X
3
1610 2.024-39 3.000 6.000 EY 5-4-9291-1
High angle yoke
3
1610 2.024-39 3.000 6.000 EY 5-4-9311-1X
High angle yoke
3
1710 2.024-39 3.000 6.000 EY 6-4-9291-1
High angle yoke
3
1710 2.024-39 3.000 6.000 EY 6-4-9301-1X
High angle yoke
3
1710 2.024-39 3.000 4.656 EY 6-4-9421-1
3
1710 2.024-39 3.000 4.656 EY 6-4-9431-1X
W460-S
1
SPL250 2.364-36 3.000 5.680 EY 250-4-361-1
1
SPL250 2.364-36 3.000 5.680 EY 250-4-371-1X
1
1610 2.364-36 3.000 5.156 EY 5-4-8641-1
1
1610 2.364-36 3.000 5.156 EY 5-4-8651-1X
1
1710 2.364-36 3.000 5.438 EY 6-4-8711-1
1
1710 2.364-36 3.000 5.438 EY 6-4-8721-1X
1
1760 2.364-36 3.000 5.438 EY 6.3-4-1551-1
1
1760 2.364-36 3.000 5.438 EY 6.3-4-1561-1X
1
1810 2.364-36 3.000 5.438 EY 6.5-4-4431-1
1
1810 2.364-36 3.000 5.438 EY 6.5-4-4441-1X
2
SPL170 1.989-30 3.000 6.580 EY 170-4-771-1
High angle yoke
2
1610 1.989-30 3.000 6.000 EY 5-4-8661-1
High angle yoke
2
1710 1.989-30 3.000 6.281 EY 6-4-8731-1
High angle yoke
3
SPL170 2.364-36 3.000 6.780 EY 170-4-781-1
High angle yoke
3
SPL170 2.364-36 3.000 6.780 EY 170-4-791-1X
High angle yoke
3
1710 2.364-36 3.000 6.500 EY 6-4-8771-1
High angle yoke
3
1710 2.364-36 3.000 6.500 EY 6-4-8781-1X
High angle yoke
22-MF, 22-MR, 28-MF, 28-MR
1 1480/1550 1.750-10 2.375 2.812 CF 4-1-3171
1
1350 1.750-10 2.375 4.000 EY 3-4-2351-1
3 1480/1550 1.750-10 2.375 2.812 CF 4-1-3171
3
1350 1.750-10 2.375 4.000 EY 3-4-2351-1
280
3
1710 1.962-10 2.625 6.125 EY 6-4-4851-1X
High angle yoke
30R
1
1550 1.962-10 2.625 4.266 EY 4-4-4071-1X
1
1610 1.962-10 2.625 5.312 EY 5-4-4471-1
1
1610 1.962-10 2.625 6.000 EY 5-4-4771X
High angle yoke
1
1610 1.962-10 2.625 4.719 EY 5-4-5121X
1
1710 1.964-10 2.625 4.500 EY 6-4-2211
.250 deep spline chamfer
1
1710 1.962-10 2.625 4.500 EY 6-4-4731-1X
.250 deep spline chamfer
1
1710 1.962-10 2.625 4.500 EY 6-4-4731X
Chamfered Counterbore
1
1710 1.962-10 2.625 6.125 EY 6-4-4851-1X
High angle yoke
1
1710 1.962-10 2.625 6.125 EY 6-4-4851X
High angle yoke
1
1710 1.962-10 2.625 5.250 EY 6-4-5151X
1
1760 1.964-10 2.625 5.625 EY 6.3-4-221X
.250 deep spline chamfer
1
1810 1.964-10 2.625 5.625 EY 6.5-4-2351X
.250 deep spline chamfer
2
1410 1.750-10 2.625 4.250 EY 3-4-2511-1
.250 deep spline chamfer
2
1550 1.750-10 2.625 4.672 EY 4-4-3581-1X
.250 deep spline chamfer
2
1610 1.750-10 2.625 6.000 EY 5-4-4761X
High angle yoke
2
1610 1.750-10 2.625 4.750 EY 5-4-5111X
2
1710 1.750-10 2.625 5.250 EY 6-4-4301X
Chamfered Counterbore
2
1710 1.750-10 2.625 6.125 EY 6-4-4861X
Chamfered Counterbore; High angle yoke
2
1710 1.750-10 2.625 4.500 EY 6-4-5581-1X
Chamfered Counterbore
2
1710 1.750-10 2.625 4.500 EY 6-4-5581X
Chamfered Counterbore
3
1410 1.750-10 2.625 4.250 EY 3-4-2511-1
All ratios except 3.70 & 4.11; .250 deep spline chamfer
3
1480 1.750-10 2.625 4.281 EY 3-4-5791-1X
.250 deep spline chamfer
3
1550 1.750-10 2.625 4.672 EY 4-4-3581-1X
.250 deep spline chamfer
3
1610 1.750-10 2.625 6.000 EY 5-4-4761X
All ratios except 3.70 & 4.11; High angle yoke
