162
J300-P10
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
5-4-6441-1X 1610 2.024 39 3.000 2.312 4.875
5-4-6481 1610 1.998 38 2.750 1.969 4.156
5-4-6481-1 1610 1.998 38 2.750 1.969 4.156
5-4-6531-1 1610 2.625 20 3.750 2.750 5.062
5-4-6891X 1610 2.250 10 3.000 3.000 5.625
5-4-6951X 1610 2.024 39 2.750 2.453 5.125
5-4-6961X 1610 2.024 39 2.750 2.438 5.938
5-4-7041-1 1610 1.962 10 2.750 2.812 5.281
5-4-7121X 1610 1.998 38 3.000 2.125 4.844
5-4-7181X 1610 2.114 32 3.000 2.250 6.000
5-4-7191 1610 2.364 36 3.000 2.688 5.156
5-4-7201X 1610 2.364 36 3.000 2.688 5.156
5-4-7211X 1610 2.364 36 3.000 2.688 5.156
5-4-7221X 1610 2.114 32 3.000 2.250 5.375
5-4-7231X 1610 2.364 36 3.000 2.703 6.000
5-4-7251X 1610 1.989 30 3.000 2.688 6.000
5-4-7261 1610 1.790 34 2.625 2.188 4.750
5-4-7261-1 1610 1.790 34 2.625 2.188 4.750
5-4-7271-1 1610 2.143 41 2.938 2.500 5.250
5-4-7301-1X 1610 1.790 34 2.625 2.188 4.750
5-4-7311-1X 1610 2.143 41 2.938 2.500 5.250
5-4-7331-1 1610 2.390 46 3.250 2.312 4.938
5-4-7341-1X 1610 2.390 46 3.250 2.312 4.938
5-4-7351-1 1610 2.374 46 3.250 2.891 4.547
5-4-7361-1X 1610 2.374 46 3.250 2.891 4.547
5-4-7381-1 1610 2.250 10 3.750 3.000 5.750
5-4-7391-1X 1610 2.250 10 3.750 3.000 5.750
5-4-7551-1 1610 2.143 41 2.938 3.000 6.500
5-4-7561 1610 2.143 41 2.938 2.500 6.000
5-4-7561-1 1610 2.143 41 2.938 2.500 6.000
5-4-7571-1X 1610 2.143 41 2.938 2.500 6.000
5-4-7571X 1610 2.143 41 2.938 2.500 6.000
5-4-7581-1 1610 1.750 10 2.500 2.250 4.720
5-4-7601-1 1610 1.998 38 2.750 2.125 7.562
5-4-7631-1 1610 1.750 10 2.500 1.953 4.125
5-4-7641-1 1610 2.343 45 3.750 3.000 5.750
5-4-7651-1X 1610 2.343 45 3.750 3.000 5.750
5-4-7781-1 1610 1.790 34 2.562 2.750 5.312
5-4-781 1610 1.750 10 2.625 2.250 4.125
5-4-7951-1 1610 2.547 49 4.000 2.750 5.500
5-4-7971 1610 2.024 39 2.625 2.250 5.312
5-4-7971-1 1610 2.024 39 2.625 2.250 5.312
5-4-7981-1 1610 2.024 39 2.625 2.234 4.719
5-4-7991 1610 2.024 39 2.625 2.250 6.000
5-4-8001 1610 1.790 34 2.625 2.438 6.188
5-4-8021-1 1610 2.274 44 2.938 2.328 4.844
5-4-8031-1X 1610 2.274 44 2.938 2.328 4.844
5-4-8061-1X 1610 1.790 34 2.562 2.750 5.312
5-4-8131-1X 1610 2.024 39 2.625 2.234 4.719
5-4-8211-1X 1610 2.260 06 3.250 2.250 4.938
5-4-8261 1610 2.024 39 3.000 2.284 6.000
5-4-8261-1 1610 2.024 39 3.000 2.281 6.000
5-4-8301 1610 2.024 39 2.625 2.500 6.000
5-4-8311-1 1610 2.274 44 3.000 2.500 5.000
5-4-8321-1 1610 2.274 44 2.938 2.500 5.000
5-4-8361-1 1610 1.962 10 2.750 2.812 5.281
5-4-8411-1X 1610 2.024 39 2.625 2.250 5.312
5-4-8411X 1610 2.024 39 2.625 2.250 5.312
5-4-8421X 1610 2.024 39 2.625 2.250 6.000
5-4-8431-1X 1610 2.274 44 2.938 2.500 5.000
5-4-8441X 1610 1.790 34 2.625 2.438 6.188
5-4-8491-1 1610 1.790 34 2.625 2.422 4.938
5-4-8501-1X 1610 1.790 34 2.625 2.422 4.938
5-4-8561-1 1610 1.790 34 2.375 2.203 4.125
5-4-8571-1X 1610 1.790 34 2.375 2.203 4.125
5-4-8581-1 1610 1.998 38 3.000 2.125 4.844
5-4-8591-1X 1610 1.998 38 3.000 2.125 4.844
5-4-8601-1 1610 2.114 32 3.000 2.234 5.375
5-4-8611-1X 1610 2.114 32 3.000 2.234 5.375
5-4-8621-1 1610 2.364 36 3.000 2.688 5.156
5-4-8631-1X 1610 2.364 36 3.000 2.688 5.156
5-4-8641-1 1610 2.364 36 3.000 2.688 5.156
5-4-8651-1X 1610 2.364 36 3.000 2.688 5.156
5-4-8661-1 1610 1.989 30 3.000 2.688 6.000
5-4-8681-1 1610 2.114 32 3.000 2.234 6.000
5-4-8691-1X 1610 2.114 32 3.000 2.234 6.000
5-4-8911-1 1610 1.790 34 2.500 2.250 5.438
5-4-8971-1 1610 1.998 38 2.750 2.125 4.000
5-4-9101-1X 1610 2.274 44 2.938 2.328 4.844
5-4-9111-1X 1610 2.143 41 2.938 2.500 5.250
5-4-9121-1X 1610 2.143 41 2.938 2.500 6.000
5-4-9121X 1610 2.143 41 2.938 2.500 6.000
5-4-9131-1X 1610 2.143 41 2.938 3.000 6.500
5-4-9141 1610 2.178 43 3.531 2.031 5.406
5-4-9141-1 1610 2.178 43 3.531 2.031 5.406
5-4-9221-1 1610 2.024 39 3.000 2.281 4.875
5-4-9231-1X 1610 2.024 39 3.000 2.281 4.875
5-4-9241-1X 1610 2.024 39 3.000 2.281 6.000
5-4-9241X 1610 2.024 39 3.000 2.284 6.000
5-4-9261-1X 1610 2.274 44 3.000 2.500 5.000
5-4-9271X 1610 2.024 39 2.625 2.500 6.000
5-4-9291-1 1610 2.024 39 3.000 2.250 6.000
5-4-9311-1X 1610 2.024 39 3.000 2.250 6.000
5-4-9351-1 1610 2.024 39 3.000 2.500 5.594
5001480 SPL55 1.790 34 2.564 2.760 4.870
5001766 SPL170 2.024 39 3.000 2.281 5.540
5001768 SPL170 2.024 39 2.625 2.500 5.750
5001782 SPL70 2.024 39 3.000 1.844 3.878
5002873 1610 2.143 41 3.000 2.188 4.680
5002874 SPL100 2.143 41 3.000 2.166 4.310
5002875 SPL100 2.143 41 3.000 2.166 4.310
5002876 1710 2.143 41 3.000 2.166 5.380
5002877 1710 2.143 41 3.000 2.166 5.380
5003553 1710 2.390 46 3.250 2.328 5.391
5003555 1760 2.390 46 3.250 2.328 5.062
5003556 1810 2.390 46 3.250 2.312 5.156
5003557 SPL140 2.390 46 3.250 2.323 5.660
5003558 SPL170 2.390 46 3.250 2.328 5.100
5005217 SPL170 2.544 49 3.820 2.682 6.040
5005579 1710 2.544 49 3.819 2.677 6.050
End Yoke Parts Listing
