Spicer DRIVELINE COMPONENTS CATALOG FLANGE & END YOKE APPLICATIONS - Manual (Page 146)

*C/L to End of Hub for EY (End Yoke); Flange Face to End of Hub for CF (Companion Flange)
•Hub machined for spedometer gear
145
MAIN TRANSMISSIONS
J300-P10
Important: See Safety Information in General Information Section (J300P-GI)
Pos Series
Spline
Data
Hub
Dia
*C/L to
End of
Hub
End Fitting
Part Number
Pos Series
Spline
Data
Hub
Dia
*C/L to
End of
Hub
End Fitting
Part Number
ES66-7 (Continued)
1 1550 1.998-38 2.750 7.031 EY 4-4-6101-1
Flanged end yoke.
1 1610 1.998-38 2.750 4.125 EY 5-4-6321
1 1610 1.998-38 2.750 4.000 EY 5-4-6321-1
1 1610 1.998-38 2.750 4.156 EY 5-4-6481
1 1610 1.998-38 2.750 4.156 EY 5-4-6481-1
1 1610 1.998-38 2.750 7.562 EY 5-4-7601-1
Flanged end yoke.
1 1710 1.998-38 2.750 5.250 EY 6-4-7301
1 1710 1.998-38 2.750 5.250 EY 6-4-7301-1
ES67-5
1 1480/1550 1.998-38 2.750 3.875 CF 4-1-6051X
Can be used w/brake; Assembly includes four 8-73-226 studs
1 1610 1.998-38 2.750 4.688 CF 5-1-6271
1 SPL140 1.998-38 2.750 4.830 EY 140-4-111-1
1 SPL170 1.998-38 2.750 4.844 EY 170-4-541-1
1 SPL90 1.998-38 2.750 7.562 EY 90-4-111-1
Can be used w/brake; Flanged end yoke.
1 SPL90 1.998-38 2.750 4.250 EY 90-4-391-1
1 SPL90 1.998-38 2.750 4.000 EY 90-4-71-1
1 1550 1.998-38 2.750 4.047 EY 4-4-4491-1
Can be used w/brake
1 1550 1.998-38 2.750 7.031 EY 4-4-6101-1
Flanged end yoke.
1 1610 1.998-38 2.750 4.125 EY 5-4-6321
Can be used w/brake
1 1610 1.998-38 2.750 4.000 EY 5-4-6321-1
Can be used w/brake
1 1610 1.998-38 2.750 4.156 EY 5-4-6481
Can be used w/brake
1 1610 1.998-38 2.750 4.156 EY 5-4-6481-1
Can be used w/brake
1 1610 1.998-38 2.750 7.562 EY 5-4-7601-1
Flanged end yoke.
1 1710 1.998-38 2.750 5.250 EY 6-4-7301
Can be used w/brake
1 1710 1.998-38 2.750 5.250 EY 6-4-7301-1
Can be used w/brake
ES70-5
1 1550 2.000-10 2.750 3.625 CF 4-1-3781
Can be used w/brake
1 1610 2.000-10 2.750 3.625 CF 5-1-3141
Can be used w/brake
1 1710 2.000-10 2.750 3.688 CF 6-1-2221
Can be used w/brake
1 1610 2.000-10 2.750 5.188 EY 5-4-1661
Can be used w/brake
1 1610 2.000-10 2.750 5.469 EY 5-4-1661-1
Can be used w/brake
1 1610 1.962-10 2.750 5.281 EY 5-4-7041-1
Can be used w/brake
1 1710 1.962-10 2.750 5.156 EY 6-4-3831
Can be used w/brake
1 1710 1.962-10 2.750 5.156 EY 6-4-3831-1
Can be used w/brake
LPSO125-10
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2271
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2351X
1 SPL250 2.500-10 3.750 6.250 EY 250-4-561-1•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611-1•
Main Transmissions — Spicer ®
LPSO125-10 (Continued)
1 1710 2.500-10 3.750 5.625 EY 6-4-6921-1X•
1 1710 2.500-10 3.750 5.625 EY 6-4-6921X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-651•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-651-1•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-781-1X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-781X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451-1•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551-1X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551X•
LPSO140-10
1 1710 2.500-10 3.750 3.625 CF 6-1-5541
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2271
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2351X
1 SPL250 2.500-10 3.750 6.250 EY 250-4-561-1•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611-1•
1 1710 2.500-10 3.750 5.625 EY 6-4-6921-1X•
1 1710 2.500-10 3.750 5.625 EY 6-4-6921X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-651•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-651-1•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-781-1X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-781X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451-1•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551-1X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551X•
LPSO150-10
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2271
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2351X
1 SPL250 2.500-10 3.750 6.250 EY 250-4-561-1•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611-1•
1 1710 2.500-10 3.750 5.625 EY 6-4-6921-1X•
1 1710 2.500-10 3.750 5.625 EY 6-4-6921X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-651•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-651-1•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-781-1X•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-781X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451-1•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551-1X•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3551X•
LPS025-10, LPS140-10, LPS150-10
1 SPL170 2.500-10 3.750 5.750 EY 170-4-471-1•
PSO100-10, PSO115-10
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2271
1 1810 2.500-10 3.750 3.625 CF 6.5-1-2351X
1 1710 2.500-10 3.750 5.625 EY 6-4-6611•
1 1710 2.500-10 3.750 5.625 EY 6-4-6611-1•
1 1760 2.500-10 3.750 6.000 EY 6.3-4-651•
1 1760 2.500-10 3.750 6.031 EY 6.3-4-651-1•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451•
1 1810 2.500-10 3.750 5.875 EY 6.5-4-3451-1•
