163
PART DA
TA
LISTING
J300-P10
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
5005580 1710 2.544 49 3.819 2.677 6.050
5005581 1760 2.544 49 3.819 2.677 5.750
5005582 1760 2.544 49 3.819 2.677 5.750
5006607 SPL100 2.024 39 3.000 1.817 4.150
5006608 SPL100 2.024 39 3.000 1.817 4.150
5006714 SPL170 2.544 49 3.820 2.675 6.810
5006976 1480 2.024 39 3.000 1.832 3.878
55-4-101-1X SPL55 1.790 34 2.564 2.760 4.870
55-4-31-1 SPL55 1.790 34 2.375 2.188 4.219
55-4-41-1X SPL55 1.790 34 2.375 2.188 4.219
55-4-71-1 SPL55 2.024 39 3.000 2.281 4.330
55-4-81-1X SPL55 2.024 39 3.000 2.281 4.330
55-4-91-1 SPL55 1.790 34 2.564 2.760 4.870
6.3-4-101 1760 2.374 46 3.250 2.625 5.438
6.3-4-101-1 1760 2.374 46 3.250 2.625 5.438
6.3-4-1021X 1760 2.364 36 3.000 2.688 5.438
6.3-4-1031 1760 2.390 46 3.250 2.328 5.062
6.3-4-1031-1 1760 2.390 46 3.250 2.328 5.062
6.3-4-1041-1X 1760 2.390 46 3.250 2.328 5.062
6.3-4-1041X 1760 2.390 46 3.250 2.328 5.062
6.3-4-1051-1 1760 2.794 54 3.750 3.000 5.970
6.3-4-1061 1760 2.143 41 2.938 2.500 5.250
6.3-4-1061-1 1760 2.143 41 2.938 2.500 5.250
6.3-4-1071-1X 1760 2.143 41 2.938 2.500 5.250
6.3-4-1071X 1760 2.143 41 2.938 2.500 5.250
6.3-4-1091-1 1760 2.250 10 3.750 3.000 5.625
6.3-4-1101-1X 1760 2.250 10 3.750 3.000 5.625
6.3-4-1141-1X 1760 2.024 39 3.000 2.312 5.188
6.3-4-1151 1760 2.390 46 3.375 3.188 6.000
6.3-4-1151-1 1760 2.390 46 3.375 3.188 6.000
6.3-4-1161-1X 1760 2.390 46 3.375 3.188 6.000
6.3-4-1161X 1760 2.390 46 3.375 3.188 6.000
6.3-4-1171 1760 2.143 41 2.938 3.000 5.812
6.3-4-1251 1760 2.544 49 4.000 2.750 5.562
6.3-4-1251-1 1760 2.544 49 4.000 2.750 5.562
6.3-4-1261X 1760 2.032 10 2.750 2.000 5.000
6.3-4-1271-1X 1760 2.374 46 3.750 2.422 5.406
6.3-4-1281-1X 1760 2.374 46 3.750 2.422 5.406
6.3-4-1281X 1760 2.374 46 3.750 2.422 5.406
6.3-4-1321 1760 2.274 44 2.938 2.328 5.094
6.3-4-1321-1 1760 2.274 44 2.938 2.328 5.094
6.3-4-1331-1X 1760 2.274 44 2.938 2.328 5.094
6.3-4-1331X 1760 2.274 44 2.938 2.328 5.094
6.3-4-1341-1X 1760 2.024 39 3.000 2.312 5.188
6.3-4-1391-1X 1760 2.374 46 3.500 2.406 5.375
6.3-4-1391X 1760 2.374 46 3.500 2.406 5.375
6.3-4-1401-1X 1760 2.500 10 3.500 2.406 5.406
6.3-4-1401X 1760 2.500 10 3.500 2.406 5.406
6.3-4-141 1760 2.149 16 2.938 3.000 5.812
6.3-4-141-1 1760 2.149 16 2.938 3.000 5.812
6.3-4-1411 1760 2.274 44 3.000 2.500 5.250
6.3-4-1411-1 1760 2.274 44 3.000 2.500 5.250
6.3-4-1421 1760 2.274 44 2.938 2.500 5.250
6.3-4-1421-1 1760 2.274 44 2.938 2.500 5.250
6.3-4-1481-1X 1760 2.274 44 2.938 2.500 5.250
6.3-4-1481X 1760 2.274 44 2.938 2.500 5.250
6.3-4-1491-1 1760 1.998 38 3.000 2.125 4.844
6.3-4-1501-1X 1760 1.998 38 3.000 2.125 4.844
6.3-4-151 1760 2.500 10 3.500 2.406 5.406
6.3-4-151-1 1760 2.500 10 3.500 2.406 5.406
6.3-4-1511-1 1760 2.114 32 3.000 2.250 5.000
6.3-4-1521-1X 1760 2.114 32 3.000 2.250 5.000
6.3-4-1531-1 1760 2.364 36 3.000 2.688 5.438
6.3-4-1541-1X 1760 2.364 36 3.000 2.688 5.438
6.3-4-1551-1 1760 2.364 36 3.000 2.688 5.438
6.3-4-1561-1X 1760 2.364 36 3.000 2.688 5.438
6.3-4-1591-1 1760 2.178 43 3.539 2.050 5.500
6.3-4-1601-1 1760 2.364 36 3.500 2.485 5.230
6.3-4-1611-1X 1760 2.364 36 3.500 2.485 5.230
6.3-4-1621-1X 1760 2.274 44 2.938 2.328 5.094
6.3-4-1621X 1760 2.274 44 2.938 2.328 5.094
6.3-4-1631-1X 1760 2.143 41 2.938 2.500 5.250
6.3-4-1641X 1760 2.143 41 2.938 3.000 5.812
6.3-4-1651-1X 1760 2.390 46 3.375 3.188 6.000
6.3-4-1651X 1760 2.390 46 3.375 3.188 6.203
6.3-4-1681 1760 2.794 54 2.750 5.625
6.3-4-1681-1 1760 2.794 54 2.750 5.625
6.3-4-1701-1 1760 2.024 39 3.000 2.250 5.625
6.3-4-171-1X 1760 2.225 06 3.000 3.250 6.000
6.3-4-171X 1760 2.225 06 3.000 3.250 6.000
6.3-4-1711-1X 1760 2.024 39 3.000 2.250 5.625
6.3-4-181X 1760 2.000 10 2.938 2.562 5.375
6.3-4-1861 1760 2.544 49 3.818 2.141 5.200
6.3-4-1861-1 1760 2.544 49 3.818 2.141 5.200
6.3-4-191X 1760 2.024 39 3.000 2.438 5.188
6.3-4-211-1X 1760 2.374 46 3.250 2.625 5.438
6.3-4-211X 1760 2.374 46 3.250 2.625 5.438
6.3-4-221X 1760 1.964 10 2.625 2.250 5.625
6.3-4-231X 1760 2.149 16 2.938 2.500 5.250
6.3-4-241-1X 1760 2.422 18 3.375 3.000 6.000
6.3-4-241X 1760 2.422 18 3.375 3.000 6.000
6.3-4-251-1X 1760 2.149 16 2.938 3.000 5.812
6.3-4-251X 1760 2.149 16 2.938 3.000 5.812
6.3-4-271 1760 2.364 18 3.500 3.375 6.125
6.3-4-271-1 1760 2.364 18 3.500 3.375 6.125
6.3-4-291 1760 2.374 46 3.250 2.875 5.625
6.3-4-291-1 1760 2.374 46 3.250 2.875 5.625
6.3-4-301-1X 1760 2.374 46 3.250 2.875 5.625
6.3-4-301X 1760 2.374 46 3.250 2.875 5.625
6.3-4-331-1X 1760 2.274 44 2.938 2.500 5.250
6.3-4-331X 1760 2.274 44 2.938 2.500 5.250
6.3-4-381 1760 2.390 46 3.500 3.375 6.000
6.3-4-381-1 1760 2.390 46 3.500 3.375 6.000
6.3-4-391 1760 2.374 46 3.500 2.406 5.375
6.3-4-391-1 1760 2.374 46 3.500 2.406 5.375
6.3-4-41 1760 2.635 20 3.750 2.750 5.562
6.3-4-41-1 1760 2.635 20 3.750 2.750 5.562
6.3-4-421 1760 2.032 10 2.750 2.000 5.000
6.3-4-51 1760 2.225 06 3.000 3.250 6.000
6.3-4-51-1 1760 2.225 06 3.000 3.250 6.000
End Yoke Parts Listing
