Spicer DRIVELINE COMPONENTS CATALOG FLANGE & END YOKE APPLICATIONS - Manual (Page 160)

159
PART DA
TA
LISTING
J300-P10
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
O.D.
Series
Spline Data
Length
Thru
Hole
*C/L to
End of
Hub
Part Number
Ground
Hub
Dia.
No.
Teeth
170-4-311-1 SPL170 2.143 41 2.938 3.000 7.190
170-4-321-1X SPL170 2.143 41 2.938 3.000 7.190
170-4-331-1 SPL170 2.143 41 2.938 3.000 5.800
170-4-341-1X SPL170 2.143 41 2.938 3.000 5.800
170-4-351-1 SPL170 2.143 41 2.938 2.500 5.320
170-4-361-1X SPL170 2.143 41 2.938 2.500 5.320
170-4-371-1 SPL170 2.143 41 2.938 2.500 6.680
170-4-381-1X SPL170 2.143 41 2.938 2.500 6.680
170-4-411-1 SPL170 2.544 49 3.750 3.000 6.000
170-4-421-1X SPL170 2.544 49 3.750 3.000 6.000
170-4-451-1 SPL170 2.250 10 3.500 3.000 5.750
170-4-461-1X SPL170 2.250 10 3.500 3.000 5.750
170-4-471-1 SPL170 2.500 10 3.750 3.000 5.750
170-4-481-1X SPL170 2.500 10 3.750 3.000 5.750
170-4-491-1 SPL170 2.750 10 3.750 3.000 5.850
170-4-501-1X SPL170 2.750 10 3.750 3.000 5.850
170-4-511-1 SPL170 2.750 10 3.750 3.000 5.850
170-4-521-1X SPL170 2.750 10 3.750 3.000 5.850
170-4-531-1 SPL170 2.750 10 3.000 5.850
170-4-541-1 SPL170 1.998 38 2.750 2.125 4.844
170-4-561-1 SPL170 2.794 54 2.750 5.600
170-4-571-1 SPL170 2.374 46 3.250 2.875 5.760
170-4-581-1X SPL170 2.374 46 3.250 2.875 5.760
170-4-591-1X SPL170 2.374 46 3.250 2.875 5.760
170-4-601-1 SPL170 2.374 46 3.250 2.875 7.250
170-4-611-1X SPL170 2.374 46 3.250 2.875 7.250
170-4-631-1 SPL170 1.774 34 2.500 2.250 6.440
170-4-641-1 SPL170 2.024 39 3.000 2.312 5.090
170-4-651-1X SPL170 2.024 39 3.000 2.312 5.090
170-4-661-1 SPL170 2.024 39 3.000 2.312 6.391
170-4-671-1X SPL170 2.024 39 3.000 2.312 6.391
170-4-681-1X SPL170 2.024 39 3.000 2.312 5.090
170-4-691-1X SPL170 2.024 39 3.000 2.312 6.391
170-4-701-1X SPL170 2.024 39 3.000 2.312 5.090
170-4-711-1 SPL170 2.390 46 3.250 2.328 5.100
170-4-721-1X SPL170 2.390 46 3.250 2.328 5.100
170-4-731-1 SPL170 2.390 46 3.250 2.328 6.438
170-4-741-1X SPL170 2.390 46 3.250 2.328 6.438
170-4-771-1 SPL170 1.989 30 3.000 2.685 6.580
170-4-781-1 SPL170 2.364 36 3.000 2.685 6.780
170-4-791-1X SPL170 2.364 36 3.000 2.685 6.780
170-4-801-1 SPL170 2.024 39 3.000 2.250 6.250
170-4-811-1X SPL170 2.024 39 3.000 2.250 6.250
170-4-821-1 SPL170 2.024 39 3.000 2.500 5.280
170-4-831-1 SPL170 2.024 39 3.000 2.500 6.500
170-4-841-1 SPL170 2.024 39 3.000 2.250 5.031
170-4-851-1X SPL170 2.024 39 3.000 2.250 5.031
170-4-861-1X SPL170 2.024 39 3.000 2.250 5.031
170-4-891-1 SPL170 2.114 32 3.000 2.250 5.000
170-4-901-1X SPL170 2.114 32 3.000 2.250 5.000
170-4-91-1 SPL170 2.274 44 2.938 2.500 5.281
170-4-921-1 SPL170 1.790 34 2.500 2.250 5.030
170-4-951-1 SPL170 2.114 32 3.000 2.250 6.312
170-4-961-1X SPL170 2.114 32 3.000 2.250 6.312
2-4-1731 1310 1.375 10 2.125 2.000 3.438
2-4-1831 1310 1.250 10 1.750 2.000 3.625
2-4-2851-1X 1310 1.125 10 1.552 1.500 3.000
2-4-3581-1X 1330 1.146 26 1.562 1.500 3.000
2-4-3801-1X 1310 1.276 29 1.875 1.500 2.938
2-4-3801X 1310 1.276 29 1.875 1.500 2.938
2-4-4191-1 1310 1.400 32 2.125 2.000 3.438
2-4-4291-1X 1330 1.276 29 1.875 1.500 2.938
2-4-4601-1 1310 1.146 26 1.844 1.375 2.938
2-4-5251X 1310 1.146 26 1.552 1.500 3.406
2-4-5311X 1330-F 1.276 29 1.875 1.500 2.938
2-4-5421X 1310 1.326 30 1.750 2.000 3.375
2-4-6111X 1330-F 1.146 26 1.562 1.500 3.000
2-4-6131-1X 1310 1.026 23 1.552 1.500 3.000
2-4-6901-1X 1310 1.146 26 1.844 1.375 2.938
2-4-7631-1 1330 1.146 26 1.844 1.375 3.562
2-4-7661-1 7290 1.146 26 1.844 1.375 3.219
2-4-7681-1X 7290 1.276 29 1.875 1.500 3.359
2-4-8051X 1330-F 1.276 29 1.875 1.500 2.938
2-4-8091-1X 1310 1.146 26 1.552 1.500 3.000
2-4-8091X 1310 1.146 26 1.552 1.500 3.000
250-4-101-1X SPL250 2.390 46 3.375 3.195 6.760
250-4-131-1 SPL250 2.143 41 2.938 2.500 5.490
250-4-141-1X SPL250 2.143 41 2.938 2.500 5.490
250-4-151-1 SPL250 2.544 49 3.750 3.000 6.250
250-4-161-1X SPL250 2.544 49 3.750 3.000 6.250
250-4-191-1 SPL250 2.500 10 3.750 3.000 6.062
250-4-201-1X SPL250 2.500 10 3.750 3.000 6.062
250-4-211-1 SPL250 2.750 10 3.750 3.000 6.300
250-4-221-1X SPL250 2.750 10 3.750 3.000 6.300
250-4-231-1 SPL250 2.750 10 3.750 3.000 6.297
250-4-241-1X SPL250 2.750 10 3.750 3.000 6.297
250-4-251-1 SPL250 2.750 10 3.000 6.310
250-4-271-1 SPL250 2.794 54 2.750 5.703
250-4-281-1 SPL250 2.374 46 3.250 2.875 5.870
250-4-291-1X SPL250 2.374 46 3.250 2.875 5.870
250-4-301-1X SPL250 2.374 46 3.250 2.875 5.870
250-4-31-1 SPL250 2.274 44 2.938 2.350 5.328
250-4-341-1 SPL250 2.390 46 3.250 2.312 5.312
250-4-351-1X SPL250 2.390 46 3.250 2.312 5.312
250-4-361-1 SPL250 2.364 36 3.000 2.685 5.680
250-4-371-1X SPL250 2.364 36 3.000 2.685 5.680
250-4-381-1 SPL250 2.024 39 3.000 2.245 5.240
250-4-391-1X SPL250 2.024 39 3.000 2.245 5.240
250-4-41-1X SPL250 2.274 44 2.938 2.350 5.328
250-4-411-1 SPL250 2.114 32 3.000 2.245 5.240
250-4-421-1X SPL250 2.114 32 3.000 2.245 5.240
250-4-471-1 SPL250 2.390 46 3.500 3.375 6.560
250-4-501-1 SPL250 2.795 55 4.725 2.047 5.413
250-4-51-1 SPL250 2.274 44 2.938 2.500 5.484
250-4-511-1 SPL250 2.635 20 3.750 2.750 6.270
250-4-521-1X SPL250 2.635 20 3.750 2.750 6.270
250-4-531-1 SPL250 2.225 06 3.000 3.250 6.240
250-4-541-1X SPL250 2.225 06 3.000 3.250 6.240
250-4-551-1 SPL250 2.750 10 4.000 2.935 6.370
250-4-561-1 SPL250 2.500 10 3.750 3.000 6.250
End Yoke Parts Listing
