EN-36 EXPLORER BALANCES
4.4 Check Weighing
Check Weighing is used to compare the weight of a sample against target limits. Three different modes can be
selected: Over and Under, Nominal Weight Tolerance, or Nominal Percent Tolerance.
4.4.1
Standard Check Weighing (default)
In the upper left portion of the home screen, select Check Weighing.
The default (or last) Check weigh limits are displayed. Place objects on the pan. The Under/Accept/Over status
is shown in the progress bar area while the actual weight of the item is shown on the main Display Line.
The CHECK WEIGHING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Application Icon
Functions
4.4.2
Edit Settings
To view or adjust the current settings
Touch the Edit Settings button. The Settings screen appears.
The Application Settings Screen.
Settings available: Over Limit, Under Limit
Functions Available: Return to Application
The check limit values are displayed in the settings screen.
To set the Over Limit value, touch the Over Limit button
To set the Under Limit value, touch the Under Limit button
A numeric input window appears.
Enter the desired Limit Weight, then press .
The display returns to the previous screen with the new value
highlighted momentarily.
To return to the CHECK WEIGHING home screen,
touch Return to Application.
